Ubiquiti UniFi WAN Switch, 3 x 10G SFP+, Shadow Mode High Availability, Dual AC Power, 1U

USW-WAN

Condition: NEW

Dhs. 1,394.07(exc. Vat)
(exc. Vat)
Dhs. 1,394.07(exc. Vat)
Shipping calculated at checkout.
    Live stock status

    Confirm Availability & Best Price

    This model is fulfilled through our verified supplier network. Message us for live stock status and pricing.

    Enquire Now
    Genuine Guarantee

    Shop with Confidence: Authentic IT Products from Major Brands.
    Shipping information

    We offer FREE DELIVERY for order over AED 200. Also no additional Cash on Delivery (COD) fee.

    Click here to know more
    Returns information

    No longer required or changed you mind ?

    We have a 7 days return policy

    Click here to know more
    Ubiquiti UniFi WAN Switch USW-WAN view 1 atomoffice
    Ubiquiti UniFi WAN Switch USW-WAN view 2 atomoffice
    Ubiquiti UniFi WAN Switch USW-WAN view 3 atomoffice
    Ubiquiti UniFi WAN Switch USW-WAN view 4 atomoffice

    UniFi Switching | WAN

    Ubiquiti UniFi WAN Switch (USW-WAN)

    A 10G SFP+ WAN switch that links two UniFi Gateways running Shadow Mode High Availability to a single ISP connection. It has one 10G SFP+ ISP uplink, two 10G SFP+ downlink ports for the gateways and one GbE port for management with UniFi Network. Two AC inputs with two internal power supplies give power redundancy in a slim 1U rack chassis, managed in UniFi Network 9.1.119 and later.

    Quick Glance

    Network Ports
    3 x 10G SFP+, 1 x GbE RJ45
    Uplink Speed
    10G SFP+ ISP uplink
    Switching Capacity
    20 Gbps
    Form Factor
    1U rack mount
    Management Type
    UniFi Network 9.1.119+

    Key Features

    One ISP line to two gateways in Shadow Mode

    The WAN Switch connects two UniFi Gateways in Shadow Mode High Availability to a single ISP connection for resilient internet connectivity. One 10G SFP+ port takes the ISP uplink and two 10G SFP+ ports run down to the gateways. Ubiquiti states an additional USW-WAN is used for deployments with multiple ISPs.

    Dual AC inputs for power redundancy

    Two universal 100–240V AC inputs feed two internal 36W AC/DC power supplies, so the switch keeps running if one power feed is lost. Maximum power consumption is 13W, and Ubiquiti positions the dual inputs for reliable operation in business-critical deployments.

    Slim 1U rack chassis managed in UniFi

    An SGCC steel 1U chassis measuring 442.4 x 120 x 43.7 mm, weighing 2.3 kg with mounting brackets, with Ethernet, SFP+ and system LEDs. The GbE RJ45 port is for management with UniFi Network 9.1.119 and later. Switching capacity is 20 Gbps with 10 Gbps non-blocking throughput.

    Detailed Specifications

    ProductUniFi WAN Switch
    Part NumberUSW-WAN
    Form FactorRack mount (1U)
    Redundancy(2) AC inputs
    ManagementEthernet
    Application Requirements (UniFi Network)Version 9.1.119 and later
    10G SFP+3 (10G/1G): (1) ISP uplink and (2) downlink ports
    1 GbE RJ451 (1G/100M/10M), for management with UniFi Network
    Switching Capacity20 Gbps
    Total Non-Blocking Throughput10 Gbps
    Forwarding Rate15 Mpps
    Power Supply(2) AC/DC, internal, 36W
    Power Method(2) Universal input, 100–240V AC, 50/60 Hz
    Power Input MethodAC input
    Supported Voltage Range100–240V AC
    Max. Power Consumption13W
    Dimensions442.4 x 120 x 43.7 mm (17.4 x 4.72 x 1.7")
    WeightWithout mounting brackets: 2.2 kg (4.85 lb); with mounting brackets: 2.3 kg (5.1 lb)
    Enclosure MaterialSGCC steel
    Mount MaterialSGCC steel
    LEDsEthernet, SFP+, System
    ESD ProtectionAir: ± 16kV, contact: ± 22kV
    NDAA CompliantYes
    CertificationsCE, FCC, IC, Anatel: 03715-25-08356
    Ambient Operating Temperature-5 to 40° C (23 to 104° F)
    Ambient Operating Humidity10 to 90% noncondensing

    Specifications are from Ubiquiti's official technical specifications and store listing for the UniFi WAN Switch (USW-WAN). Ubiquiti states one WAN Switch serves a single ISP; deployments with multiple ISPs use an additional unit.

    Need-to-Know

    • One USW-WAN links two Shadow Mode High Availability UniFi Gateways to a single ISP. Ubiquiti states an additional USW-WAN is used for deployments with multiple ISPs or ISP failover.
    • Shadow Mode High Availability needs two UniFi Gateways. This switch connects them to the ISP; it does not replace a gateway.
    • The three SFP+ ports run at 10G or 1G. Ubiquiti does not list SFP+ modules or cables as included.
    • Ubiquiti's specification lists no VLAN, PoE or Layer 2 feature table for this switch; it is built for the WAN side of a gateway pair. Ubiquiti does not state the power cord plug type.

    Best For / Customer Benefits

    Customer Benefits

    • Expert help designing a Shadow Mode gateway pair and planning the SFP+ links to your ISP.
    • Dual AC inputs keep the WAN side running when one power feed is lost.
    • Managed with the rest of your UniFi network in the UniFi Network application.
    • VAT invoice issued with every order for UAE business buyers.

    Best For

    Gateway pairs running Shadow Mode High Availability
    Businesses that cannot afford internet downtime from a gateway failure
    Server and network racks with dual power feeds
    Multi-WAN designs, with one WAN Switch per ISP line

    Frequently Asked Questions

    It links two UniFi Gateways running Shadow Mode High Availability to a single ISP connection. The ISP line connects to the 10G SFP+ uplink port, and the two gateways connect to the two 10G SFP+ downlink ports for resilient internet connectivity.

    Ubiquiti states that an additional USW-WAN is used for deployments with multiple ISPs and for ISP failover deployments, so plan one WAN Switch per ISP line that has to reach both gateways.

    Yes. Ubiquiti lists two AC inputs, each universal 100–240V AC at 50/60 Hz, with two internal 36W AC/DC power supplies. Maximum power consumption is 13W.

    Ubiquiti lists UniFi Network version 9.1.119 and later. The switch is managed through its GbE RJ45 port, with Ethernet, SFP+ and system LEDs on the chassis.
