Ubiquiti UniFi Switch Flex Mini 2.5G, 5-Port 2.5 GbE Switch, PoE or USB-C Powered, Compact Desktop

USW-Flex-2.5G-5

Condition: NEW

Dhs. 348.75(exc. Vat)
(exc. Vat)
Dhs. 348.75(exc. Vat)
Shipping calculated at checkout.
    Live stock status

    Confirm Availability & Best Price

    This model is fulfilled through our verified supplier network. Message us for live stock status and pricing.

    Enquire Now
    Genuine Guarantee

    Shop with Confidence: Authentic IT Products from Major Brands.
    Shipping information

    We offer FREE DELIVERY for order over AED 200. Also no additional Cash on Delivery (COD) fee.

    Click here to know more
    Returns information

    No longer required or changed you mind ?

    We have a 7 days return policy

    Click here to know more
    Ubiquiti Switch Flex Mini 2.5G USW-Flex-2.5G-5 view 1 atomoffice
    Ubiquiti Switch Flex Mini 2.5G USW-Flex-2.5G-5 view 2 atomoffice
    Ubiquiti Switch Flex Mini 2.5G USW-Flex-2.5G-5 view 3 atomoffice
    Ubiquiti Switch Flex Mini 2.5G USW-Flex-2.5G-5 view 4 atomoffice

    Ubiquiti UniFi Switching

    Ubiquiti UniFi Switch Flex Mini 2.5G (USW-Flex-2.5G-5)

    The Switch Flex Mini 2.5G is a compact 5-port 2.5 GbE switch from Ubiquiti. All five RJ45 ports run at up to 2.5 Gbps, and one of them doubles as a PoE input, so the switch can be powered over the network cable or from the included 5V, 1A USB-C adapter. It sits on a desk and is managed in the UniFi Network application, version 8.6.9 and later.

    Quick Glance

    Network Ports
    5 x 2.5 GbE RJ45 (1 PoE in)
    Switching Capacity
    25 Gbps
    Form Factor
    Compact desktop
    Management Type
    UniFi Network 8.6.9+

    Key Features

    Five 2.5 GbE ports in a compact switch

    All five RJ45 ports support 2.5G, 1G, 100M and 10M. Ubiquiti rates switching capacity at 25 Gbps, total non-blocking throughput at 12.5 Gbps and the forwarding rate at 19 Mpps, with a 4,000-entry MAC address table. The polycarbonate unit measures 117.1 x 90 x 21.2 mm and weighs 206 g.

    Powered by PoE or the included USB-C adapter

    One of the five ports is a 2.5 GbE PoE input, so the switch can take its power from an upstream PoE port (44V to 57V). Alternatively, use the included 5V, 1A USB-C adapter. Maximum power consumption is 5W on AC/DC input and 6.4W on PoE input. The switch has no PoE output.

    Managed in UniFi Network

    Managed from the UniFi Network application (8.6.9 and later), it supports up to 256 VLANs, STP and RSTP, storm control, multicast and broadcast rate limiting, egress rate limiting, flow control, port isolation, port mirroring, jumbo frames and loop protection.

    Detailed Specifications

    2.5 GbE RJ45 Ports5 (2.5G/1G/100M/10M)
    PoE Input Port1 of the 5 ports (2.5 GbE PoE input port for power)
    Switching Capacity25 Gbps
    Total Non-Blocking Throughput12.5 Gbps
    Forwarding Rate19 Mpps
    MAC Address Table Size4,000
    Supported VLANs256
    STP & RSTPYes
    Egress Rate LimitYes
    Flow ControlYes
    Storm ControlYes
    Multicast & Broadcast Rate LimitingYes
    Port IsolationYes
    Port MirroringYes
    Jumbo FramesYes
    Loop ProtectionYes
    Power Method(1) USB Type-C, 5V DC, 1A; (1) PoE
    Power Input MethodUSB input, PoE
    Power SupplyAC/DC, external, 5W (5V, 1A USB-C adapter included)
    Supported Voltage Range4.8—5.2V DC/USB; 44V—57V PoE
    Max. Power Consumption5W (AC/DC input); 6.4W (PoE input)
    Dimensions117.1 x 90 x 21.2 mm (4.6 x 3.5 x 0.8")
    Form FactorCompact desktop
    Weight206 g (7.3 oz)
    Enclosure MaterialPolycarbonate
    Ambient Operating Temperature-20 to 45° C (-4 to 113° F)
    Ambient Operating Humidity10 to 90% noncondensing
    NDAA CompliantYes
    CertificationsCE, FCC, IC, Anatel
    ManagementEthernet
    Application Requirements (UniFi Network)Version 8.6.9 and later

    Specifications are from Ubiquiti's official tech specs and store listing for the Switch Flex Mini 2.5G (USW-Flex-2.5G-5). Ubiquiti states the EU version comes with an EU power plug only. Ubiquiti may update specifications without notice.

    Need-to-Know

    • The switch has five 2.5 GbE ports in total; one of them is the PoE input port used for power. Ubiquiti's spec lists no PoE output, so it cannot power other devices.
    • Two ways to power it: from an upstream PoE port (44V—57V PoE) or from the included 5V, 1A USB-C adapter.
    • Ubiquiti states that the EU version comes with an EU power plug only. Ubiquiti sells EU and UK versions; check the plug on the version supplied if you will use the USB-C adapter.
    • Ubiquiti lists the form factor as compact desktop and gives no other mounting option for this model.
    • Managing the switch needs the UniFi Network application, version 8.6.9 or later.

    Best For / Customer Benefits

    Customer Benefits

    • Expert consultation to choose between the Flex Mini 2.5G and other UniFi switches for your port and PoE needs.
    • Help planning how to power the switch: from an upstream PoE port or the included USB-C adapter.
    • VAT invoice issued with every order for UAE business buyers.
    • Genuine Ubiquiti hardware, specified from Ubiquiti's own published spec sheet.

    Best For

    Bringing 2.5 GbE to a desk, meeting room or workstation cluster
    Extending a UniFi network where only one cable run is available
    Small offices adding a few 2.5 GbE wired devices

    Frequently Asked Questions

    Either over PoE, through one of its five 2.5 GbE ports (44V—57V PoE), or from the included 5V, 1A USB-C adapter. Ubiquiti gives maximum power consumption as 5W on AC/DC input and 6.4W on PoE input.

    No. Ubiquiti lists one PoE input port, used to power the switch itself, and no PoE output. To power PoE devices you need a PoE switch, such as the Switch Flex 2.5G PoE.

    All five RJ45 ports support 2.5G, 1G, 100M and 10M. Ubiquiti rates switching capacity at 25 Gbps, total non-blocking throughput at 12.5 Gbps and the forwarding rate at 19 Mpps.

    It is managed in the UniFi Network application, version 8.6.9 and later. Ubiquiti lists up to 256 VLANs, STP and RSTP, storm control, port isolation, port mirroring, flow control, jumbo frames and loop protection.

    Adding 2.5 GbE to a desk or meeting room?

    Tell us what you need to connect and how you plan to power the switch, and we will confirm whether the Switch Flex Mini 2.5G fits.
