Ubiquiti UniFi Indoor Cable Cat6 CMP, 305 m Box, Plenum-Rated, 23 AWG UTP, White

U-Cable-C6-CMP

Condition: NEW

Dhs. 1,347.57(exc. Vat)
(exc. Vat)
Dhs. 1,347.57(exc. Vat)
Shipping calculated at checkout.
    Live stock status

    Confirm Availability & Best Price

    This model is fulfilled through our verified supplier network. Message us for live stock status and pricing.

    Enquire Now
    Genuine Guarantee

    Shop with Confidence: Authentic IT Products from Major Brands.
    Shipping information

    We offer FREE DELIVERY for order over AED 200. Also no additional Cash on Delivery (COD) fee.

    Click here to know more
    Returns information

    No longer required or changed you mind ?

    We have a 7 days return policy

    Click here to know more
    Ubiquiti UniFi Indoor Cable Cat6 CMP U-Cable-C6-CMP view 1 atomoffice
    Ubiquiti UniFi Indoor Cable Cat6 CMP U-Cable-C6-CMP view 2 atomoffice
    Ubiquiti UniFi Indoor Cable Cat6 CMP U-Cable-C6-CMP view 3 atomoffice

    Ubiquiti UniFi Indoor Cable

    Ubiquiti UniFi Indoor Cable Cat6 CMP (305 m)

    The Ubiquiti UniFi Indoor Cable Cat6 CMP (U-Cable-C6-CMP) is a 305 m (1,000 ft) box of Category 6 UTP Ethernet cable for indoor deployments in spaces that require plenum-rated cabling. It has four twisted pairs of 23 AWG solid bare copper, an anti-crosstalk divider and a ripcord, inside a white, fire-resistant FRPVC jacket rated CMP to NFPA 262.

    Quick Glance

    Cable Length
    305 m (1,000 ft) box
    Cable Type
    Category 6 UTP, CMP (plenum)
    Conductor
    Solid bare copper, 23 AWG

    Key Features

    Plenum (CMP)-rated, fire-resistant jacket

    Ubiquiti rates the cable CMP to the NFPA 262 flame test, for indoor deployments in environments that require plenum-rated cabling. The white jacket is flame retardant polyvinyl chloride (FRPVC), 5.6 ± 0.2 mm in diameter.

    Category 6 UTP with anti-crosstalk divider

    Four colour-coded twisted pairs of 23 AWG solid bare copper are separated by an anti-crosstalk divider, with a ripcord to strip the jacket. Ubiquiti lists electrical transmission standards ANSI/TIA-568.2-D, ISO/IEC 11801 (Edition 2.2) and IEC 61156-5 (Edition 2.1).

    305 m box for building-wide runs

    One box holds 305 m (1,000 ft) of cable. The box measures 476 x 306 x 419 mm and weighs 14.7 kg. Install between 0 and 60°C, keep bends to a minimum radius of 22.4 mm, and operate from -20 to 60°C.

    Detailed Specifications

    ProductUniFi Indoor Cable Cat6 CMP
    Length305 m (1,000 ft)
    TypeCategory 6
    Flame RatingCMP
    Operating EnvironmentIndoor
    Shielding TypeUTP
    Conductor TypeSolid bare copper
    Conductor Wire Gauge23 AWG
    Twisting4 twisted pairs with color code. Pair 1: white-blue / blue; Pair 2: white-orange / orange; Pair 3: white-green / green; Pair 4: white-brown / brown
    Anti-Crosstalk DividerYes
    RipcordYes
    Jacket ColorWhite
    Jacket Diameter5.6 ± 0.2 mm
    Jacket MaterialFlame retardant polyvinyl chloride (FRPVC)
    Bend RadiusMin. 22.4 mm (0.88")
    Box Dimensions476 x 306 x 419 mm (18.7 x 12 x 16.5")
    Box Weight14.7 kg (32.4 lb)
    Installation Temperature0 to 60°C (32 to 140°F)
    Ambient Operating Temperature-20 to 60°C (-4 to 140°F)
    Ambient Storage Temperature-20 to 75°C (-4 to 167°F)
    Electrical TransmissionANSI/TIA-568.2-D; ISO/IEC 11801 (Edition 2.2); IEC 61156-5 (Edition 2.1)
    Flame TestNFPA 262 (CMP)
    Material and ConstructionUL 444; CSA 22.2 NO.214; EU Directive 2011/65/EU (RoHS2); EU Directive 2006/95/EC (LVD)

    Specifications are taken from Ubiquiti's official technical specifications and store listing for the UniFi Indoor Cable Cat6 CMP, U-Cable-C6-CMP. Ubiquiti does not state a data rate or maximum link length for this cable.

    Need-to-Know

    • This is an indoor cable: Ubiquiti lists its operating environment as Indoor. For outdoor runs, choose a cable Ubiquiti rates for outdoor use.
    • CMP is the plenum flame rating (NFPA 262). Ubiquiti also makes a riser-rated version, the UniFi Indoor Cable Cat6 CMR (U-Cable-C6-CMR), for spaces that do not require plenum-rated cabling.
    • Ubiquiti lists no connectors for this cable and its text states no data rate or maximum link length. Terminate it with connectors suited to solid 23 AWG conductors.
    • Install the cable between 0 and 60°C and keep bends no tighter than the 22.4 mm minimum bend radius.

    Best For / Customer Benefits

    Customer Benefits

    • Plenum (CMP)-rated, fire-resistant FRPVC jacket tested to NFPA 262.
    • Anti-crosstalk divider separating four twisted pairs of 23 AWG solid bare copper.
    • A ripcord in the jacket for quicker stripping during termination.
    • A full 305 m box, so long runs can be pulled without joins.

    Best For

    Structured cabling in plenum spaces such as ceiling voids used for air handling
    Indoor runs to UniFi access points, cameras and switches
    Installers who need a full 305 m box for a building project

    Frequently Asked Questions

    The CMP version is plenum-rated to the NFPA 262 flame test, for environments that require plenum-rated cabling. Ubiquiti also sells a riser (CMR)-rated version, the U-Cable-C6-CMR. Both are 305 m boxes of Category 6 UTP cable with 23 AWG solid bare copper conductors and an anti-crosstalk divider.

    One box holds 305 m (1,000 ft) of cable. Ubiquiti gives the box dimensions as 476 x 306 x 419 mm and the box weight as 14.7 kg (32.4 lb).

    No screen is listed. Ubiquiti gives the shielding type as UTP (unshielded twisted pair). The four twisted pairs are separated by an anti-crosstalk divider, and the jacket has a ripcord for stripping.

    Ubiquiti lists the operating environment as Indoor, so this cable is for indoor installation. Its ambient operating temperature is -20 to 60°C and its installation temperature is 0 to 60°C.
