Ubiquiti UniFi Gateway Max UXG-Max, 2.3 Gbps IDS/IPS Routing, Five 2.5 GbE Ports, Multi-WAN

UXG-Max

Condition: NEW

Dhs. 699.37(exc. Vat)
(exc. Vat)
Dhs. 699.37(exc. Vat)
Shipping calculated at checkout.
    Live stock status

    Confirm Availability & Best Price

    This model is fulfilled through our verified supplier network. Message us for live stock status and pricing.

    Enquire Now
    Genuine Guarantee

    Shop with Confidence: Authentic IT Products from Major Brands.
    Shipping information

    We offer FREE DELIVERY for order over AED 200. Also no additional Cash on Delivery (COD) fee.

    Click here to know more
    Returns information

    No longer required or changed you mind ?

    We have a 7 days return policy

    Click here to know more
    Ubiquiti Gateway Max UXG-Max view 1 atomoffice
    Ubiquiti Gateway Max UXG-Max view 2 atomoffice
    Ubiquiti Gateway Max UXG-Max view 3 atomoffice
    Ubiquiti Gateway Max UXG-Max view 4 atomoffice

    UniFi Gateway | Compact Desktop

    Ubiquiti UniFi Gateway Max (UXG-Max)

    A compact, multi-WAN independent gateway with full 2.5G support for small-to-medium sites. It routes at up to 2.3 Gbps with IDS/IPS on UniFi Gateway firmware 4.1 or later, has five 2.5 GbE RJ45 ports, balances traffic across multiple WAN links and adds a Layer 7 firewall, license-free SD-WAN and VPN. It is managed from a CloudKey, Official UniFi Hosting or UniFi OS Server running UniFi Network 8.1.113 and later. USB-C powered, adapter included.

    Quick Glance

    Routing Speed
    Up to 2.3 Gbps with IDS/IPS
    WAN Interface
    2.5 GbE RJ45, up to 4 WAN ports
    Processor
    Quad-core ARM Cortex-A53, 1.5 GHz
    Form Factor
    Compact desktop

    Key Features

    2.3 Gbps routing with IDS/IPS and Layer 7 firewall

    Ubiquiti rates IDS/IPS throughput at 2.3 Gbps with UniFi Gateway firmware 4.1 or later, with 55,000+ IDS/IPS signatures with CyberSecure. It adds a stateful and application-aware Layer 7 firewall, DPI and traffic identification, zone-based filtering by region, domain and app, content filtering and ad blocking.

    Full 2.5G ports, multi-WAN, SD-WAN and VPN

    Five 2.5 GbE RJ45 ports: one WAN port and four LAN ports, one of them remappable to WAN, with a maximum WAN port count of 4 and multi-WAN load balancing. License-free SD-WAN, Site Magic, IPsec and OpenVPN site-to-site links, WireGuard, OpenVPN and L2TP VPN servers and OSPF dynamic routing.

    Independent gateway, managed from your UniFi console

    The Gateway Max is managed with a CloudKey, Official UniFi Hosting or UniFi OS Server running UniFi Network 8.1.113 and later. It has a quad-core 1.5 GHz processor and 2 GB memory, measures 141.8 x 127.6 x 30 mm, draws 9.6W at most and is USB-C powered with the adapter included.

    Detailed Specifications

    ProductGateway Max
    Part NumberUXG-Max
    IDS/IPS Throughput2.3 Gbps (With UniFi Gateway firmware 4.1 or later.)
    Form FactorCompact desktop
    Dimensions141.8 x 127.6 x 30 mm (5.6 x 5 x 1.2")
    Application Requirements (UniFi Network)Version 8.1.113 and later
    Managed WithCloudKey, Official UniFi Hosting, or UniFi OS Server
    Default WAN Ports(1) 2.5 GbE RJ45
    Max. WAN Port Count4
    2.5 GbE RJ455 (2.5G/1G/100M/10M)
    Port Use(1) 2.5 GbE WAN port, (4) 2.5 GbE LAN ports, including (1) remappable to WAN
    Stateful FirewallYes
    Application-Aware Layer 7 FirewallYes
    DPI & Traffic IdentificationYes
    Zone-Based Firewall Advanced Filtering (Regions, Domains, Apps)Yes
    Content FilteringYes
    Intrusion Prevention (IPS/IDS)Yes
    IDS/IPS Signatures55,000+ With CyberSecure
    Ad BlockingYes
    License-Free SD-WANYes
    Site-to-Site VPNSite Magic, IPsec, OpenVPN
    VPN Server / Teleport Zero-Configuration VPNYes (Available on the Default site when paired with a CloudKey)
    VPN Server / WireGuardYes
    VPN Server / OpenVPNYes
    VPN Server / L2TPYes
    VPN ClientOpenVPN, WireGuard
    Multi-WAN Load BalancingYes
    Dynamic RoutingOSPF
    Advanced QoSYes
    Multicast DNS (mDNS)Yes
    Advanced NAT (SNAT / DNAT / Masquerade / NAT Pooling / 1-to-1 NAT)Yes
    Integrated RADIUS ServerYes
    RADIUS over TLS (RadSec)Yes
    Additional Internet Failover with UniFi LTE BackupYes
    Internet Quality and Outage ReportingYes
    MAC Address Table Size2,000
    Virtual Network OverrideYes
    All Traffic FlowsYes (Available when managed with a UniFi OS Server, CloudKey Enterprise, or Official UniFi Hosting.)
    ProcessorQuad-core ARM® Cortex®-A53 at 1.5 GHz
    System Memory2 GB
    ManagementEthernet, Bluetooth
    LEDsEthernet, System
    Button(1) Factory reset
    Enclosure MaterialPolycarbonate
    Weight520 g (1.1 lb)
    ESD/EMP ProtectionAir: ± 8kV, contact: ± 4kV
    Ambient Operating Temperature-10 to 40° C (14 to 104° F)
    Ambient Operating Humidity5 to 95% noncondensing
    NDAA CompliantYes
    CertificationsCE, FCC, IC, Anatel: 04873-25-08356
    Power MethodUSB type C (5V DC/3A)
    Power SupplyUSB type C (5V DC/3A) (Adapter included)
    Supported Voltage Range100–240V AC
    Max. Power Consumption9.6W
    Heat Dissipation33 BTU/hr

    Specifications are from Ubiquiti's official technical specifications and store listing for the UniFi Gateway Max (UXG-Max). The 2.3 Gbps IDS/IPS figure applies with UniFi Gateway firmware 4.1 or later; real performance depends on the traffic and features in use.

    Need-to-Know

    • The Gateway Max is an independent gateway: it needs a CloudKey, Official UniFi Hosting or UniFi OS Server running UniFi Network 8.1.113 and later to manage it.
    • Ubiquiti's 2.3 Gbps IDS/IPS figure applies with UniFi Gateway firmware 4.1 or later.
    • The store lists one 2.5 GbE WAN port and four 2.5 GbE LAN ports, one remappable to WAN; the specification gives a maximum WAN port count of 4. Confirm your WAN plan with us before ordering.
    • All Traffic Flows is available when managed with a UniFi OS Server, CloudKey Enterprise or Official UniFi Hosting. The Teleport VPN server is available on the Default site when paired with a CloudKey.
    • Ubiquiti's specification lists no built-in wireless radio for this gateway. Power is USB type C (5V DC/3A) with the adapter included; Ubiquiti does not state the adapter's plug type.

    Best For / Customer Benefits

    Customer Benefits

    • Every port is 2.5 GbE, so neither the WAN nor the LAN side is held to 1 Gbps.
    • No licence needed for SD-WAN, site-to-site VPN or the VPN servers Ubiquiti lists.
    • Low power draw of 9.6W at most, from a USB type C adapter that comes in the box.
    • Expert advice on whether the Gateway Max or a UniFi Cloud Gateway suits your site.

    Best For

    Small-to-medium sites that already run a CloudKey or UniFi OS Server
    Offices on 2.5G internet or with 2.5G switching behind the gateway
    Sites with two or more internet lines that need load balancing
    Branches that need site-to-site VPN back to head office

    Frequently Asked Questions

    Yes. Ubiquiti describes the Gateway Max as an independent gateway managed with a CloudKey, Official UniFi Hosting or UniFi OS Server, with UniFi Network 8.1.113 and later. If you want the gateway and the UniFi Network application in one box, a UniFi Cloud Gateway is the alternative.

    Ubiquiti lists IDS/IPS throughput of 2.3 Gbps with UniFi Gateway firmware 4.1 or later. All five ports are 2.5 GbE RJ45, supporting 2.5G/1G/100M/10M.

    Yes. Ubiquiti lists multi-WAN load balancing and a maximum WAN port count of 4. The store describes one 2.5 GbE WAN port plus four 2.5 GbE LAN ports, one of which is remappable to WAN. Additional internet failover is supported with the separate UniFi LTE Backup.

    Site-to-site VPN with Site Magic, IPsec and OpenVPN; WireGuard, OpenVPN and L2TP VPN servers; Teleport zero-configuration VPN on the Default site when paired with a CloudKey; and OpenVPN and WireGuard VPN clients. Ubiquiti also lists license-free SD-WAN.

    Over USB type C at 5V DC/3A, with the adapter included according to Ubiquiti. Supported voltage range is 100–240V AC and maximum power consumption is 9.6W. Ubiquiti does not state the adapter's plug type.
