Ubiquiti UniFi Enterprise Access Hub EAH-8, 8 Doors, 8 PoE+ Reader Ports, Battery Backup Input

EAH-8

Condition: NEW

Dhs. 4,161.75(exc. Vat)
(exc. Vat)
Dhs. 4,161.75(exc. Vat)
Shipping calculated at checkout.
    Live stock status

    Confirm Availability & Best Price

    This model is fulfilled through our verified supplier network. Message us for live stock status and pricing.

    Enquire Now
    Genuine Guarantee

    Shop with Confidence: Authentic IT Products from Major Brands.
    Shipping information

    We offer FREE DELIVERY for order over AED 200. Also no additional Cash on Delivery (COD) fee.

    Click here to know more
    Returns information

    No longer required or changed you mind ?

    We have a 7 days return policy

    Click here to know more
    Ubiquiti Enterprise Access Hub EAH-8 view 1 atomoffice
    Ubiquiti Enterprise Access Hub EAH-8 view 2 atomoffice
    Ubiquiti Enterprise Access Hub EAH-8 view 3 atomoffice
    Ubiquiti Enterprise Access Hub EAH-8 view 4 atomoffice

    UniFi Access Door Hub

    Ubiquiti UniFi Enterprise Access Hub (EAH-8)

    The Ubiquiti Enterprise Access Hub (EAH-8) is an enterprise-grade UniFi Access hub with entry and exit control for up to eight doors and battery backup support. It has eight lock terminals (12V or dry), eight request-to-exit and eight door position inputs, an emergency input, four AUX terminals and eight PoE+ ports for Access Readers. Ubiquiti rates it for up to 10,000 users. It is wall-mounted, for indoor use, and managed in UniFi Access.

    Quick Glance

    Device Type
    Access hub, up to 8 doors
    Network Interface
    10 x GbE RJ45 (8 PoE+ out)
    Operating Temperature
    0 to 40° C, indoor only
    Form Factor
    Wall mount, steel housing

    Key Features

    Eight doors from one hub

    Controls and monitors up to eight doors, with eight lock terminals (12V or dry contact) for broad lock compatibility, eight request-to-exit inputs, eight door position inputs and four AUX terminals for chimes, sirens or door openers. Ubiquiti rates the hub for up to 10,000 users.

    Eight PoE+ ports for readers and paired cameras

    Eight PoE+ outputs at 50V DC supply power and data to connected UniFi Access Readers and paired cameras, with up to 30W per port and 190W aggregated. The hub has ten 10/100/1000 Base-T ports in total and is managed in the UniFi Access application.

    Battery backup and emergency input

    A dedicated PP45 cable input connects an external 32–48V DC lead acid backup battery for continued operation during power interruptions. A dedicated emergency input lets the system respond immediately to fire alarms or critical override signals. Main power is a universal 100–240V AC input.

    Detailed Specifications

    Supported Doors8
    Maximum User Count10,000
    Input Terminals(8) Door exit request, (8) Door position, (1) Emergency
    Dry Output Relay(8) Lock terminals (12V or Dry); (4) AUX terminals for advanced setup (Chime/Siren/Door opener)
    Powered Output RelayLock: 12V DC, 1A; AUX: Dry only
    Max. Cable Length, UA-Lock-Electric (400mA)24 AWG: 25 m (82 ft); 22 AWG: 42 m (138 ft); 20 AWG: 66 m (217 ft); 18 UACC-Cable-DoorLockRelay: 100 m (328 ft)
    Max. Cable Length, UA-Lock-Magnetic-540kg (500mA)24 AWG: 20 m (66 ft); 22 AWG: 32 m (105 ft); 20 AWG: 51 m (167 ft); 18 UACC-Cable-DoorLockRelay: 80 m (262 ft)
    Max. Cable Length, UA-Lock-Magnetic-270kg (800mA)24 AWG: 12 m (39 ft); 22 AWG: 20 m (66 ft); 20 AWG: 30 m (98 ft); 18 UACC-Cable-DoorLockRelay: 46 m (151 ft)
    Max. Cable Length, other locks (1A)24 AWG: 9 m (30 ft); 22 AWG: 15 m (49 ft); 20 AWG: 24 m (79 ft); 18 UACC-Cable-DoorLockRelay: 36 m (118 ft)
    Networking Interface(10) 10/100/1000 Base-T
    PoE Interface(8) PoE+ outputs, 50V DC, 30W per port (Max 190W aggregated)
    Max. PoE Wattage per Port30W
    LEDsW/B
    Buttons(1) Factory reset
    PoE Cabling RequirementsCat 5e cabling is the minimum performance category recommended. Minimum conductor gauge between the PSE or power injector and the PD: 26 AWG (0.13 mm²) for patch cords; 24 AWG (0.21 mm²) for horizontal or riser cable.
    Power MethodUniversal input, 100–240V AC, Max. 4.4A, 50/60 Hz; 32–48V DC Lead Acid Battery, Max. 7.5A @32V
    Battery Backup Input(1) Battery backup input (32–48V), dedicated PP45 cable input for an external backup battery
    Power SupplyAC/DC, internal
    Max. Power Consumption240W
    Dimensions379 x 355 x 105 mm (15 x 14 x 4.1")
    WeightDevice: 9.1 kg (20 lb); Mount: 624 g (1.4 lb)
    Enclosure MaterialSGCC steel housing with polycarbonate cover
    Mount MaterialSGCC steel
    MountingWall
    Installation EnvironmentIndoor only
    Ambient Operating Temperature0 to 40° C (32 to 104° F)
    Ambient Operating Humidity5 to 95% noncondensing
    CertificationsCE, FCC, IC, UL 294, CAN/ULC-60839-11-1
    UL 294 LevelDestructive attack: Level I; Line security: Level I; Endurance: Level I; Standby power: Level I
    CAN/ULC-60839-11-1 GradeGrade assignment: I
    NDAA CompliantYes
    UL 294 StatementCompliance with IEEE 802.3 specifications was not verified as part of UL 294.
    Management ApplicationUniFi Access
    DocumentEAH-8, Ver 01

    Specifications are Ubiquiti's own, from its technical specification and store pages for the Enterprise Access Hub (EAH-8). Readers, locks, sensors and the backup battery are not listed as part of the hub.

    Need-to-Know

    • Ubiquiti describes the backup battery as external: the hub has a dedicated PP45 cable input for a 32–48V DC lead acid battery. Ubiquiti does not list a battery as part of the hub.
    • The EAH-8 is rated for indoor use only, from 0 to 40° C. Install it in a comms room or cabinet, not on an exposed wall.
    • The eight PoE+ outputs share a 190W aggregated budget, with up to 30W on any one port. Check the combined draw of the readers and paired cameras you connect.
    • Ubiquiti publishes maximum lock cable lengths by lock type and wire gauge, from 9 m for other 1A locks on 24 AWG up to 100 m for the UA-Lock-Electric on UACC-Cable-DoorLockRelay. Plan lock cable runs against those figures.
    • Readers, locks, door sensors and the backup battery are separate items; Ubiquiti lists only terminals and ports for them on the hub.

    Best For / Customer Benefits

    Customer Benefits

    • Entry and exit control for up to eight doors from a single wall-mounted hub.
    • Eight PoE+ ports power UniFi Access Readers and paired cameras over one cable each.
    • External battery backup input and a dedicated emergency input for fire alarm or override signals.
    • UL 294 and CAN/ULC-60839-11-1 listed, and NDAA compliant.

    Best For

    Office buildings and floors with up to eight controlled doors
    Sites that need door control to keep running on battery backup
    Installers building a UniFi Access system with PoE-powered readers

    Frequently Asked Questions

    Up to eight. Ubiquiti lists eight lock terminals (12V or dry), eight request-to-exit inputs and eight door position inputs, so each of the eight doors has its own lock output, exit request and door position sensor input. Ubiquiti rates the hub for up to 10,000 users.

    Yes. Eight PoE+ outputs provide power and data to connected UniFi Access Readers and paired cameras, at 50V DC with up to 30W per port and 190W aggregated. The hub has ten 10/100/1000 Base-T ports in total.

    The hub has a dedicated PP45 cable input for an external 32–48V DC lead acid backup battery, which Ubiquiti states supports continued operation during power interruptions. The battery is not listed as part of the hub.

    Ubiquiti lists a dedicated emergency input that enables an immediate system response to fire alarms or critical override signals. The four AUX terminals can be used for chimes, sirens or door openers.

    It is wall-mounted and rated for indoor use only, from 0 to 40° C and 5 to 95% noncondensing humidity. It measures 379 x 355 x 105 mm and the device weighs 9.1 kg, with a 624 g steel mount.
