Ubiquiti UniFi Access Door Hub UA-Hub-Door, Single-Door Controller, PoE++ In, 4 PoE+ Out, DIN-Rail

UA-Hub-Door

Condition: NEW

Dhs. 1,208.07(exc. Vat)
(exc. Vat)
Dhs. 1,208.07(exc. Vat)
Shipping calculated at checkout.
    Live stock status

    Confirm Availability & Best Price

    This model is fulfilled through our verified supplier network. Message us for live stock status and pricing.

    Enquire Now
    Genuine Guarantee

    Shop with Confidence: Authentic IT Products from Major Brands.
    Shipping information

    We offer FREE DELIVERY for order over AED 200. Also no additional Cash on Delivery (COD) fee.

    Click here to know more
    Returns information

    No longer required or changed you mind ?

    We have a 7 days return policy

    Click here to know more
    Ubiquiti Access Door Hub UA-Hub-Door view 1 atomoffice
    Ubiquiti Access Door Hub UA-Hub-Door view 2 atomoffice
    Ubiquiti Access Door Hub UA-Hub-Door view 3 atomoffice
    Ubiquiti Access Door Hub UA-Hub-Door view 4 atomoffice

    UniFi Access Door Controller

    Ubiquiti UniFi Access Door Hub UA-Hub-Door Single-Door Controller

    The Access Door Hub is Ubiquiti's single-door controller for UniFi Access, providing complete entry and exit control via connected Access Readers. It powers from one PoE++ cable, supplies four PoE+ outputs for readers and paired UniFi Protect cameras or Chime, and drives the lock from 12V or dry relay terminals. A dedicated emergency input, door position and exit-request inputs, DIN-rail mounting and support for up to 6,000 users complete the hub.

    Quick Glance

    Device Type
    Single-door access hub
    Supported Credentials
    Via connected Access Readers
    Network Interface
    (5) 10/100/1000 Base-T
    Operating Temperature
    0 to 40° C, indoor only
    Form Factor
    DIN-rail mount

    Key Features

    Complete control of one door

    Dedicated control and monitoring for one door, with 12V and dry switchable lock terminals to support a wide range of locking hardware. Two AUX terminals drive an external siren and an automatic door opener, and inputs cover request to exit, request to enter, remote release and the door position sensor. Up to 6,000 users are supported.

    One PoE++ cable in, four PoE+ ports out

    A single Gigabit PoE++ RJ45 input (50V DC, 1A) carries power and data with no separate power adapter. Four PoE+ outputs supply 30W per port, 45W aggregated, to two UniFi Access readers and two UniFi Protect cameras or a UniFi Protect Chime. Maximum consumption is 30W without PoE output and 50W with it.

    Emergency input and DIN-rail mounting

    A dedicated emergency input enables immediate system response to fire alarms or critical override signals. The polycarbonate hub mounts on a DIN rail (mount included) for indoor installation from 0 to 40° C, and it is UL 294 and CAN/ULC-60839-11-1 listed and NDAA compliant.

    Detailed Specifications

    Supported Doors1
    Maximum User Count6,000
    Input Terminals(2) Door exit request, (1) Door position, (1) Emergency
    Digital InputRequest to exit, request to enter, remote release, door position sensor
    Dry Output RelayLock: 30V DC, 1A; Aux: 30V DC, 1A
    Powered Output RelayLock: 12V DC, 1A; Aux: 12V DC, 0.33A; 12V DC, 0.33A
    Connected DevicesTwo UniFi Access readers and two UniFi Protect cameras or UniFi Protect Chime
    Management ApplicationAccess
    Networking Interface(5) 10/100/1000 Base-T
    PoE Interface(1) PoE++ input, 50V DC, 1A; (4) PoE+ outputs, 50V DC, 30W per port (Max 45W aggregated)
    LEDsW/B
    Buttons(1) Factory reset
    Power MethodPoE++; UL 294 Power-limited Class 2 PSU; UL 60950-1/62368-1 LPS/PS2 PSU
    Max. Power Consumption30W (without PoE output); 50W (with PoE output)
    PoE Cabling RequirementsCat 5e cabling is the minimum performance category recommended. Minimum conductor gauge between the PSE or power injector and the hub: 26 AWG (0.13 mm²) for patch cords; 24 AWG (0.21 mm²) for horizontal or riser cable.
    UA-Lock-Electric (400mA)24 AWG: 25 m (82 ft); 22 AWG: 42 m (138 ft); 20 AWG: 66 m (217 ft); 18 AWG UACC-Cable-DoorLockRelay: 100 m (328 ft)
    UA-Lock-Magnetic-540kg (500mA)24 AWG: 20 m (66 ft); 22 AWG: 32 m (105 ft); 20 AWG: 51 m (167 ft); 18 AWG UACC-Cable-DoorLockRelay: 80 m (262 ft)
    UA-Lock-Magnetic-270kg (800mA)24 AWG: 12 m (39 ft); 22 AWG: 20 m (66 ft); 20 AWG: 30 m (98 ft); 18 AWG UACC-Cable-DoorLockRelay: 46 m (151 ft)
    Other locks (1A)24 AWG: 9 m (30 ft); 22 AWG: 15 m (49 ft); 20 AWG: 24 m (79 ft); 18 AWG UACC-Cable-DoorLockRelay: 36 m (118 ft)
    Dimensions174.9 x 126 x 32.9 mm (6.9 x 5 x 1.3")
    Weight363 g (12.8 oz)
    Enclosure MaterialPolycarbonate
    Mount MaterialPolycarbonate
    MountingDIN-rail (included)
    Indoor and Outdoor UseIndoor only
    Ambient Operating Temperature0 to 40° C (32 to 104° F)
    Ambient Operating Humidity5 to 95% noncondensing
    CertificationsCE, FCC, IC, UL 294, CAN/ULC-60839-11-1
    UL 294 LevelDestructive attack: Level I; Line security: Level I; Endurance: Level I; Standby power: Level I
    CAN/ULC-60839-11-1 GradeGrade assignment: 1
    NDAA CompliantYes
    UL 294 StatementCompliance with IEEE 802.3 (at or af) specifications was not verified as part of UL 294.

    Specifications are taken from Ubiquiti's official technical specification and store listing for the Access Door Hub, UA-Hub-Door. Lock cable lengths are Ubiquiti's recommended maximums per lock type and wire gauge.

    Need-to-Know

    • The Door Hub controls one door. Credentials are read by the UniFi Access readers connected to it; Ubiquiti lists no reader, keypad or camera on the hub itself.
    • The hub is rated for indoor use only, from 0 to 40° C. Mount it in a cabinet or ceiling space, not at the door outdoors.
    • It needs a PoE++ source on its input port. The four PoE+ outputs share a 45W aggregate budget, 30W per port maximum.
    • Lock cable runs depend on the lock's current and the wire gauge: Ubiquiti's maximum for a 1A lock on 24 AWG is 9 m, rising to 36 m on 18 AWG UACC-Cable-DoorLockRelay.

    Best For / Customer Benefits

    Customer Benefits

    • One PoE++ cable powers the hub and, through four PoE+ outputs, the readers and cameras at the door.
    • 12V and dry switchable lock terminals suit a wide range of locking hardware.
    • Emergency, door position and exit-request inputs plus two AUX terminals for a siren and a door opener.
    • UL 294 and CAN/ULC-60839-11-1 listed, and NDAA compliant.

    Best For

    Adding UniFi Access control to a single office or server-room door
    Doors with a reader on each side, or a reader plus Protect camera
    Installers who want lock, sensors and readers powered from one PoE++ run

    Frequently Asked Questions

    Ubiquiti states it connects to two UniFi Access readers and two UniFi Protect cameras or a UniFi Protect Chime, powered from its four PoE+ output ports. The lock connects to the 12V or dry lock terminals, and two AUX terminals can drive an external siren and an automatic door opener.

    From one PoE++ input (50V DC, 1A) on an RJ45 port that also carries Gigabit data, so no separate power adapter is needed. It draws 30W maximum without PoE output and 50W with PoE output.

    It has a 12V powered lock output (12V DC, 1A) and a dry lock relay (30V DC, 1A), switchable to support a wide range of locking hardware. Ubiquiti publishes maximum cable lengths for its UA-Lock-Electric and UA-Lock-Magnetic locks and for other locks up to 1A.

    Ubiquiti describes a dedicated emergency input that enables immediate system response to fire alarms or critical override signals. The hub also has two door exit request inputs and a door position input.

    No. Ubiquiti rates the Door Hub for indoor use only, with an operating temperature of 0 to 40° C and 5 to 95% noncondensing humidity. It mounts on a DIN rail, and the mount is included.
