Ubiquiti UISP Fiber Instant UF-Instant, GPON CPE SFP Module, SC/APC, 1G SFP Interface, 20 km Reach

UF-Instant

Condition: NEW

Dhs. 197.25(exc. Vat)
(exc. Vat)
Dhs. 197.25(exc. Vat)
Shipping calculated at checkout.
    Live stock status

    Confirm Availability & Best Price

    This model is fulfilled through our verified supplier network. Message us for live stock status and pricing.

    Enquire Now
    Genuine Guarantee

    Shop with Confidence: Authentic IT Products from Major Brands.
    Shipping information

    We offer FREE DELIVERY for order over AED 200. Also no additional Cash on Delivery (COD) fee.

    Click here to know more
    Returns information

    No longer required or changed you mind ?

    We have a 7 days return policy

    Click here to know more
    Ubiquiti Fiber Instant UF-Instant view 1 atomoffice
    Ubiquiti Fiber Instant UF-Instant view 2 atomoffice
    Ubiquiti Fiber Instant UF-Instant view 3 atomoffice
    Ubiquiti Fiber Instant UF-Instant view 4 atomoffice

    Ubiquiti UISP Fiber GPON CPE

    Ubiquiti UISP Fiber Instant GPON CPE (UF-Instant)

    The Ubiquiti Fiber Instant (UF-Instant) is compact GPON customer-premises equipment (CPE) in an SFP form factor. It has one SC/APC GPON port on the fiber side and connects directly into a GbE SFP cage, taking its power from the SFP slot. Ubiquiti lists 2.488 Gbps downstream and 1.244 Gbps upstream line rates and a 20 km physical reach. It works only with Ubiquiti's Fiber OLT, not third-party OLTs.

    Quick Glance

    Data Speed
    2.488 Gbps down / 1.244 Gbps up
    Connector Interface
    SC/APC GPON to 1G SFP
    Wavelength
    TX 1310 nm / RX 1490 nm
    Max Distance
    20 km physical reach

    Key Features

    GPON CPE that plugs into an SFP cage

    The Fiber Instant has (1) SC/APC ITU-G.984 GPON WAN port and (1) SGMI Ethernet LAN interface, and connects directly into a GbE SFP cage. Power comes from the SFP slot at 3.3V, with a maximum power consumption of 2W.

    2.488 Gbps down, 1.244 Gbps up, 20 km reach

    Ubiquiti lists a total non-blocking line rate of 2.488 Gbps downstream and 1.244 Gbps upstream, transmitting at 1310 nm and receiving at 1490 nm, with Scrambled NRZ line code and a physical reach of 20 km. The optical module's normal range is 0.5 to 5 dBm TX and -8 to -28 dBm RX.

    For Ubiquiti Fiber OLT networks only

    Ubiquiti states this device is only compatible with the Fiber OLT and cannot be used with third-party OLTs. It is managed through Ethernet in-band and PON, and its zinc alloy and stainless steel enclosure measures 69.5 x 13.7 x 11.3 mm and weighs 30 g.

    Detailed Specifications

    ProductFiber Instant
    Manufacturer Part NumberUF-Instant
    Device TypeCompact GPON customer-premises equipment (CPE) with a 1G SFP interface
    OLT CompatibilityFiber OLT only; cannot be used with third-party OLTs
    Management InterfaceEthernet In-Band; PON
    Networking Interface(1) SC/APC, ITU-G.984 GPON WAN; (1) SGMI, Ethernet LAN
    Operating WavelengthTX 1310 nm; RX 1490 nm
    Line CodeScrambled NRZ
    Optical Interface Nominal Bit RateDownstream 2488.32 Mbit/s; Upstream 1244.16 Mbit/s
    Normal Range of Optical ModuleTX 0.5 to 5 dBm; RX -8 to -28 dBm
    Physical Reach20 km
    Total Non-Blocking Line Rate, Downstream2.488 Gbps
    Total Non-Blocking Line Rate, Upstream1.244 Gbps
    Power MethodSFP
    Supported Voltage Range3.3V
    Max. Power Consumption2W
    Dimensions69.5 x 13.7 x 11.3 mm (2.7 x 0.5 x 0.5")
    Weight30 g (1 oz)
    Enclosure MaterialsZinc alloy, stainless steel
    Ambient Operating Temperature-10 to 45° C (14 to 113° F)
    Operating Humidity10 to 90% noncondensing
    CertificationsCE, FCC, IC
    NDAA CompliantYes

    Specifications are from Ubiquiti's technical specifications page and official store listing for the UISP Fiber Instant (UF-Instant). Ubiquiti states it works only with its Fiber OLT.

    Need-to-Know

    • The Fiber Instant is only compatible with Ubiquiti's Fiber OLT. Ubiquiti states it cannot be used with third-party OLTs, so it will not work on an ISP's or another vendor's GPON network.
    • It connects directly into a GbE SFP cage and is powered by the SFP slot (3.3V, 2W max). Ubiquiti does not publish a list of host devices in its text; check that your router or switch has a free SFP cage.
    • The fiber port is SC/APC. Use a fiber patch cable with an SC/APC connector; no fiber cable is listed as included.
    • Ubiquiti rates the module for -10 to 45° C ambient operating temperature and 10 to 90% noncondensing humidity.

    Best For / Customer Benefits

    Customer Benefits

    • Fits directly into a GbE SFP cage and is powered from the SFP slot, as a compact GPON CPE.
    • 20 km physical reach with 2.488 Gbps downstream and 1.244 Gbps upstream line rates.
    • Managed through Ethernet in-band and PON on a Ubiquiti Fiber OLT network.
    • Supplied with a VAT invoice for business purchasing.

    Best For

    Subscriber connections on a Ubiquiti Fiber OLT GPON network
    Turning a router or switch SFP cage into a GPON endpoint
    Fiber deployments built on Ubiquiti UISP Fiber OLTs

    Frequently Asked Questions

    No. Ubiquiti states the Fiber Instant is only compatible with the Fiber OLT and cannot be used with third-party OLTs. It is for GPON networks built on Ubiquiti's own Fiber OLT.

    It is a GPON CPE with a 1G SFP interface that connects directly into a GbE SFP cage, and it takes its power from the SFP slot (3.3V, 2W maximum). The fiber side is an SC/APC GPON port.

    Ubiquiti lists a total non-blocking line rate of 2.488 Gbps downstream and 1.244 Gbps upstream (nominal 2488.32 / 1244.16 Mbit/s) and a physical reach of 20 km. The LAN side is a 1G SFP interface.

    Ubiquiti lists an operating wavelength of 1310 nm for TX and 1490 nm for RX, with Scrambled NRZ line code. The optical module's normal range is 0.5 to 5 dBm TX and -8 to -28 dBm RX.

    Building a UISP Fiber network?

    Tell us about your Fiber OLT and the routers or switches at each subscriber site, and we will help you confirm the Fiber Instant fits.
