Ubiquiti Access Point U7 Pro Wall, WiFi 7 with 6 GHz, Wall-Mounted, 140 m² Coverage, 300+ Clients

U7-Pro-Wall

Condition: NEW

Dhs. 823.05(exc. Vat)
(exc. Vat)
Dhs. 823.05(exc. Vat)
Shipping calculated at checkout.
    Live stock status

    Confirm Availability & Best Price

    This model is fulfilled through our verified supplier network. Message us for live stock status and pricing.

    Enquire Now
    Genuine Guarantee

    Shop with Confidence: Authentic IT Products from Major Brands.
    Shipping information

    We offer FREE DELIVERY for order over AED 200. Also no additional Cash on Delivery (COD) fee.

    Click here to know more
    Returns information

    No longer required or changed you mind ?

    We have a 7 days return policy

    Click here to know more
    Ubiquiti Access Point U7 Pro Wall, WiFi 7 with 6 GHz, Wall-Mounted, 140 m² Coverage, 300+ Clients atomoffice
    Ubiquiti Access Point U7 Pro Wall, WiFi 7 with 6 GHz, Wall-Mounted, 140 m² Coverage, 300+ Clients atomoffice
    Ubiquiti Access Point U7 Pro Wall, WiFi 7 with 6 GHz, Wall-Mounted, 140 m² Coverage, 300+ Clients atomoffice
    Ubiquiti Access Point U7 Pro Wall, WiFi 7 with 6 GHz, Wall-Mounted, 140 m² Coverage, 300+ Clients atomoffice

    UniFi Wall-Mounted WiFi 7 Access Point

    Ubiquiti UniFi U7 Pro Wall WiFi 7 Access Point

    The Ubiquiti U7 Pro Wall is a wall-mounted WiFi 7 access point with 6 spatial streams and 6 GHz support, tailored for home builders with seamless installation options. It gives room-level coverage of up to 140 m² (1,500 ft²) in a low-profile form factor, handles 300+ connected devices, connects over a 2.5 GbE uplink and is powered by PoE+.

    Quick Glance

    Wireless Standard
    WiFi 7 with 6 GHz support
    Max Speed
    5.8 Gbps on 6 GHz (BW320)
    Coverage
    140 m² (1,500 ft²)
    Client Capacity
    300+ devices
    Power Type
    PoE+ (22W max.)

    Key Features

    Tri-radio WiFi 7 with 6 GHz and MLO

    Six spatial streams split as 2 x 2 MU-MIMO on each of the 6 GHz, 5 GHz and 2.4 GHz bands, with maximum data rates of 5.8 Gbps on 6 GHz (BW320), 4.3 Gbps on 5 GHz (BW240) and 688 Mbps on 2.4 GHz (BW40). Ubiquiti's store lists Multi-Link Operation support. 6 GHz operation depends on the country.

    Wall-first form for room-level installs

    A low-profile 150 x 103 x 36 mm unit weighing 580 g, wall-mounted with the mount included and minimal visible hardware. Optional paintable covers, a Flush Mount and a Table Stand are sold separately for different room finishes and placements.

    2.5 GbE PoE+ uplink for 300+ devices

    One 1/2.5 GbE RJ45 port carries data and PoE+ power, with a maximum power consumption of 22W and a supported voltage range of 44-57V DC. Rated for 300+ connected devices, with up to 8 BSSIDs per radio, wireless meshing, fast roaming (802.11r/k/v), PPSK and RADIUS-assigned VLANs.

    Detailed Specifications

    ProductAccess Point U7 Pro Wall
    Manufacturer Part NumberU7-Pro-Wall
    WiFi StandardWiFi 7 (With 6 GHz support)
    Spatial Streams6
    Coverage Area140 m² (1,500 ft²)
    Max. Client Count300+
    Uplink2.5 GbE
    MountingWall (Mount Included)
    Power MethodPoE+
    Dimensions150 x 103 x 36 mm (5.9 x 4.1 x 1.4")
    MIMO / 6 GHz2 x 2 (DL/UL MU-MIMO)
    MIMO / 5 GHz2 x 2 (DL/UL MU-MIMO)
    MIMO / 2.4 GHz2 x 2 (DL/UL MU-MIMO)
    Antenna Gain / 6 GHz6 dBi
    Antenna Gain / 5 GHz5 dBi
    Antenna Gain / 2.4 GHz4 dBi
    Max. TX Power / 6 GHz23 dBm
    Max. TX Power / 5 GHz26 dBm
    Max. TX Power / 2.4 GHz22 dBm
    Max. BSSIDs8 per Radio
    Channel BandwidthHT 20/40, VHT 20/40/80/160, HE 20/40/80/160, EHT 20/40/80/160/240/320 (MHz)
    Operating FrequencyUS/CA: 2400 - 2472 MHz; U-NII-1: 5150 - 5250 MHz; U-NII-2A: 5250 - 5350 MHz; U-NII-2C: 5470 - 5725 MHz; U-NII-3: 5725 - 5850 MHz; U-NII-5 to U-NII-8: 5925 - 7125 MHz. Worldwide: 2400 - 2483.5 MHz, 5150 - 5850 MHz, 5925 - 7125 MHz (for worldwide, it depends on the regulatory region)
    Max. Data Rate / 6 GHz5.8 Gbps (BW320)
    Max. Data Rate / 5 GHz4.3 Gbps (BW240)
    Max. Data Rate / 2.4 GHz688 Mbps (BW40)
    Supported Data Rates / 802.11be (WiFi 7)7.3 Mbps to 5.8 Gbps (MCS0 - MCS13 NSS1/2, EHT 20/40/80/160/240/320)
    Supported Data Rates / 802.11ax7.3 Mbps to 2.4 Gbps (MCS0 - MCS11 NSS1/2, HE 20/40/80/160)
    Supported Data Rates / 802.11ac (WiFi 5)6.5 Mbps to 1.7 Gbps (MCS0 - MCS9 NSS1/2, VHT 20/40/80/160)
    Supported Data Rates / 802.11n6.5 Mbps to 300 Mbps (MCS0 - MCS15, HT 20/40)
    Wireless MeshingYes
    Band SteeringYes
    802.11v BSS Transition ManagementYes
    802.11r Fast RoamingYes
    802.11k Radio Resource Management (RRM)Yes
    Advanced Radio ManagementYes
    Passpoint (Hotspot 2.0)Yes
    WiFi Speed LimitingYes
    WiFi SchedulesYes
    Dynamic RADIUS-assigned VLANYes
    Captive Hotspot Portal / Custom Branding Landing PageYes
    Captive Hotspot Portal / Voucher AuthenticationYes
    Captive Hotspot Portal / Payment-Based AuthenticationYes
    Captive Hotspot Portal / External Portal Server SupportYes
    Captive Hotspot Portal / Password AuthenticationYes
    Captive Hotspot Portal / Guest Network IsolationYes
    Private Pre-Shared Key (PPSK)Yes
    Client Device IsolationYes
    RADIUS over TLS (RadSec)Yes
    Networking Interface(1) 1/2.5 GbE RJ45 port
    Max. Power Consumption22W
    Supported Voltage Range44–57V DC
    Weight580 g (1.3 lb)
    Enclosure MaterialPolycarbonate, aluminum
    Mount MaterialAluminum
    LEDs / SystemWhite/Blue
    Ambient Operating Temperature-30 to 60° C (-22 to 140° F)
    Ambient Operating Humidity5 to 95% noncondensing
    NDAA CompliantYes
    CertificationsCE, FCC, IC, Anatel: 10022-24-08356
    ManagementEthernet
    Application Requirements / UniFi NetworkVersion 8.1.113 and later

    All specifications are Ubiquiti's own, from its official tech specs and store pages. 6 GHz operation depends on the country and local regulations. Flush Mount, Table Stand and paintable covers are sold separately.

    Need-to-Know

    • 6 GHz operation is supported only in the countries Ubiquiti lists, so 6 GHz availability depends on the country and its local regulations. The 2.4 GHz and 5 GHz bands are not affected by this note.
    • The wall mount is included. The Flush Mount, Table Stand and paintable covers are optional accessories sold separately and are not part of this product.
    • The U7 Pro Wall is powered by PoE+ through its single RJ45 port. Ubiquiti lists no power adapter for it, so plan a PoE+ switch port or PoE+ adapter for each access point.
    • Managing the U7 Pro Wall needs the UniFi Network application, version 8.1.113 or later.

    Best For / Customer Benefits

    Customer Benefits

    • WiFi 7 on three bands with 6 spatial streams and up to 5.8 Gbps on 6 GHz
    • Low-profile wall-mounted design with the mount included
    • Optional paintable covers, Flush Mount and Table Stand for different room finishes
    • One cable per access point: data and PoE+ power over a 2.5 GbE RJ45 port
    • Guest portals, PPSK, RadSec and RADIUS-assigned VLANs for managed networks

    Best For

    Hotel rooms, apartments and villas wired room by room
    Home builders and fit-out contractors
    Offices and meeting rooms with wall cable points
    UniFi deployments moving to WiFi 7

    Frequently Asked Questions

    The U7 Pro Wall supports 6 GHz, but Ubiquiti limits 6 GHz operation to the countries on its own supported list, and availability depends on local regulations. Ubiquiti's spec also notes that worldwide operating frequencies depend on the regulatory region. Contact us before ordering if 6 GHz is essential to your design; the 2.4 GHz and 5 GHz bands work regardless.

    It is built for wall mounting in individual rooms: a low-profile 150 x 103 x 36 mm unit weighing 580 g, with the wall mount included and optional paintable covers, Flush Mount and Table Stand sold separately. Ubiquiti rates it for the same 140 m² (1,500 ft²), 300+ devices, 6 spatial streams and 2.5 GbE uplink, with a maximum power consumption of 22W.

    By PoE+ over its single 1/2.5 GbE RJ45 port. Ubiquiti gives a maximum power consumption of 22W and a supported voltage range of 44-57V DC. Ubiquiti lists no power adapter in the product, so each access point needs a PoE+ switch port or a separately bought PoE+ adapter.

    Ubiquiti's store lists Multi-Link Operation support for the U7 Pro Wall, for improved latency and resiliency. It is managed in the UniFi Network application, version 8.1.113 or later.
