    UniFi WiFi 7 Indoor/Outdoor Mesh Access Point

    Ubiquiti UniFi U7 Mesh WiFi 7 Indoor/Outdoor Access Point

    The Ubiquiti U7 Mesh is a compact indoor/outdoor WiFi 7 access point with an integrated long-range antenna system. A directional 5 GHz antenna handles the mesh backhaul while an omni antenna serves local clients at the same time. It covers up to 140 m² (1,500 ft²), supports 200+ connected devices, is IPX6 rated when installed with the outdoor mount, and ships with a PoE adapter and wall, pole and table stand mounts.

    Quick Glance

    Wireless Standard
    WiFi 7, dual-band 2.4/5 GHz
    Max Speed
    4.3 Gbps on 5 GHz (BW240)
    Coverage
    140 m² (1,500 ft²)
    Client Capacity
    200+ devices
    Power Type
    PoE, adapter included (13W max.)

    Key Features

    Dual-antenna mesh performance

    A directional 5 GHz antenna (10 dBi) for the mesh backhaul plus an omnidirectional antenna (6 dBi on 5 GHz, 3 dBi on 2.4 GHz) for local client coverage at the same time. 2 x 2 MU-MIMO on each band, up to 4.3 Gbps on 5 GHz (BW240, depending on regulatory region) and 688 Mbps on 2.4 GHz.

    Indoor or outdoor, IPX6 rated

    IPX6-rated protection supports outdoor deployments when installed with the included outdoor mount. Wall, pole and table stand mounts are included, the enclosure is UV-stabilized polycarbonate, and Ubiquiti rates it for -30 to 60° C ambient operating temperature.

    2.5 GbE PoE, MLO ready

    One 2.5 GbE RJ45 port carries data and PoE power (13W max., 42.5-57V DC), and a PoE adapter is included. Ubiquiti lists the U7 Mesh as MLO ready: Multi-Link Operation support for improved latency and resiliency. Rated for 200+ connected devices and 140 m² (1,500 ft²).

    Detailed Specifications

    ProductAccess Point U7 Mesh
    WiFi StandardWiFi 7
    Spatial Streams4
    Coverage Area140 m² (1,500 ft²)
    Max. Client Count200+
    Uplink2.5 GbE (Cables with shorter boots are recommended)
    MountingWall, Pole, Table stand (Mounts included)
    WeatherproofingIPX6 (Installed with the outdoor mount)
    Power MethodPoE
    Dimensions⌀48.5 x 159.5 mm (⌀1.9 x 6.3")
    MIMO / 5 GHz2 x 2 (DL/UL MU-MIMO)
    MIMO / 2.4 GHz2 x 2 (DL/UL MU-MIMO)
    Antenna Gain / 5 GHzOmnidirectional: 6 dBi; Directional: 10 dBi
    Antenna Gain / 2.4 GHz3 dBi
    Max. TX Power / 5 GHz24 dBm
    Max. TX Power / 2.4 GHz23 dBm
    Max. BSSIDs8 per Radio
    Channel BandwidthHT 20/40, VHT 20/40/80/160, HE 20/40/80/160, EHT 20/40/80/160/240 (MHz)
    Max. Data Rate / 5 GHz4.3 Gbps (BW240) (Depends on regulatory region)
    Max. Data Rate / 2.4 GHz688 Mbps (BW40)
    Supported Data Rates / 802.11be (WiFi 7)7.3 Mbps to 4.3 Gbps (MCS0 - MCS13 NSS1/2, EHT 20/40/80/160/240)
    Supported Data Rates / 802.11ax (WiFi 6)7.3 Mbps to 2.4 Gbps (MCS0 - MCS11 NSS1/2, HE 20/40/80/160)
    Supported Data Rates / 802.11ac (WiFi 5)6.5 Mbps to 1.7 Gbps (MCS0 - MCS9 NSS1/2, VHT 20/40/80/160)
    Supported Data Rates / 802.11n6.5 Mbps to 300 Mbps (MCS0 - MCS15, HT 20/40)
    Wireless MeshingYes
    Band SteeringYes
    802.11v BSS Transition ManagementYes
    802.11r Fast RoamingYes
    802.11k Radio Resource Management (RRM)Yes
    Advanced Radio ManagementYes
    Passpoint (Hotspot 2.0)Yes
    WiFi Speed LimitingYes
    WiFi SchedulesYes
    Dynamic RADIUS-assigned VLANYes
    Captive Hotspot Portal / Custom Branding Landing PageYes
    Captive Hotspot Portal / Voucher AuthenticationYes
    Captive Hotspot Portal / Payment-Based AuthenticationYes
    Captive Hotspot Portal / External Portal Server SupportYes
    Captive Hotspot Portal / Password AuthenticationYes
    Captive Hotspot Portal / Guest Network IsolationYes
    Private Pre-Shared Key (PPSK)Yes
    Client Device IsolationYes
    RADIUS over TLS (RadSec)Yes
    Networking Interface(1) 2.5 GbE RJ45 port
    Max. Power Consumption13W
    Includes PoE AdapterYes
    Supported Voltage Range42.5–57V DC
    Weight313 g (11 oz)
    Enclosure MaterialUV-stabilized polycarbonate
    Mount MaterialUV-stabilized polycarbonate
    LEDs / SystemR/G/B/W
    Ambient Operating Temperature-30 to 60° C (-22 to 140° F)
    Ambient Operating Humidity5 to 95% noncondensing
    NDAA CompliantYes
    CertificationsCE, FCC, IC
    ManagementEthernet
    Application Requirements / UniFi NetworkVersion 10.1.85 and later
    Application Requirements / Mobile AppUniFi iOS: Version 10.32.1 and later; Android: Version 10.35.1 and later

    All specifications are Ubiquiti's own, from its official tech specs and store pages. IPX6 applies when installed with the outdoor mount. The 4.3 Gbps 5 GHz maximum (BW240) depends on the regulatory region.

    Need-to-Know

    • The IPX6 rating applies when the U7 Mesh is installed with the outdoor mount, as Ubiquiti states. Use that mount for any exposed outdoor position.
    • A PoE adapter is included. Ubiquiti does not state the adapter's plug type or wattage, so ask us if you need it for a specific socket type.
    • Ubiquiti recommends cables with shorter boots for the 2.5 GbE uplink port.
    • The U7 Mesh is a dual-band 2.4/5 GHz access point; Ubiquiti lists no 6 GHz operation for it. The 4.3 Gbps 5 GHz maximum (BW240) depends on the regulatory region.
    • Managing the U7 Mesh needs the UniFi Network application, version 10.1.85 or later.

    Best For / Customer Benefits

    Customer Benefits

    • One access point for indoor or outdoor use, IPX6 rated with the outdoor mount
    • Directional 5 GHz backhaul plus omni client coverage at the same time
    • PoE adapter and wall, pole and table stand mounts included
    • WiFi 7 with up to 4.3 Gbps on 5 GHz over a 2.5 GbE uplink

    Best For

    Extending UniFi WiFi to gardens, terraces and courtyards
    Wireless mesh links between buildings or to outdoor areas
    Indoor rooms where running cable to a ceiling is hard
    Pool decks, car parks and other exposed outdoor spots

    Frequently Asked Questions

    Yes. Ubiquiti describes it as a compact indoor/outdoor access point with IPX6-rated protection when installed with the included outdoor mount, and rates it for -30 to 60° C ambient operating temperature and 5 to 95% noncondensing humidity.

    Ubiquiti pairs a directional 5 GHz antenna (10 dBi) for the mesh backhaul with an omnidirectional antenna (6 dBi on 5 GHz) for local client coverage, so it can hold a reliable mesh link to another UniFi access point and serve nearby devices at the same time.

    It is powered by PoE over its single 2.5 GbE RJ45 port, with a maximum power consumption of 13W and a supported voltage range of 42.5-57V DC. Ubiquiti states that a PoE adapter is included. It can also run from a PoE switch port.

    Ubiquiti lists the U7 Mesh as MLO ready, describing it as Multi-Link Operation support for improved latency and resiliency. It is a dual-band 2.4/5 GHz WiFi 7 access point with no 6 GHz operation.

    Ubiquiti lists wall, pole and table stand mounting with the mounts included, and refers to an included outdoor mount for IPX6 installation. The access point is a slim ⌀48.5 x 159.5 mm cylinder weighing 313 g.
