Ubiquiti Access Point U6 Mesh Pro, Indoor/Outdoor WiFi 6, 185 m² Coverage, GbE Passthrough, IPX6

U6-Mesh-Pro

Condition: NEW

Dhs. 724.47(exc. Vat)
(exc. Vat)
Dhs. 724.47(exc. Vat)
Shipping calculated at checkout.
    Live stock status

    Confirm Availability & Best Price

    This model is fulfilled through our verified supplier network. Message us for live stock status and pricing.

    Enquire Now
    Genuine Guarantee

    Shop with Confidence: Authentic IT Products from Major Brands.
    Shipping information

    We offer FREE DELIVERY for order over AED 200. Also no additional Cash on Delivery (COD) fee.

    Click here to know more
    Returns information

    No longer required or changed you mind ?

    We have a 7 days return policy

    Click here to know more
    Ubiquiti Access Point U6 Mesh Pro, Indoor/Outdoor WiFi 6, 185 m² Coverage, GbE Passthrough, IPX6 atomoffice
    Ubiquiti Access Point U6 Mesh Pro, Indoor/Outdoor WiFi 6, 185 m² Coverage, GbE Passthrough, IPX6 atomoffice
    Ubiquiti Access Point U6 Mesh Pro, Indoor/Outdoor WiFi 6, 185 m² Coverage, GbE Passthrough, IPX6 atomoffice
    Ubiquiti Access Point U6 Mesh Pro, Indoor/Outdoor WiFi 6, 185 m² Coverage, GbE Passthrough, IPX6 atomoffice

    UniFi WiFi 6 Indoor/Outdoor Access Point

    Ubiquiti UniFi U6 Mesh Pro Indoor/Outdoor WiFi 6 Access Point

    The Ubiquiti U6 Mesh Pro is an indoor/outdoor WiFi 6 access point with 4 spatial streams, an integrated omnidirectional super antenna and a gigabit passthrough port. It covers up to 185 m² (2,000 ft²), handles 250+ connected devices, connects over a GbE uplink with one GbE passthrough port, and is powered by PoE with a PoE adapter included. It is rated IPX6 for outdoor exposed use and mounts on a wall or pole, with mounts included.

    Quick Glance

    Wireless Standard
    WiFi 6, 4 spatial streams
    Max Speed
    2.4 Gbps on 5 GHz (BW160)
    Coverage
    185 m² (2,000 ft²)
    Client Capacity
    250+ devices
    Power Type
    PoE (9W max.), adapter included

    Key Features

    Integrated omnidirectional super antenna

    8 dBi antenna gain on both 5 GHz and 2.4 GHz gives 185 m² (2,000 ft²) of coverage. 2 x 2 MU-MIMO on each band, with maximum data rates of 2.4 Gbps on 5 GHz (BW160) and 573.5 Mbps on 2.4 GHz (BW40), and 250+ connected devices.

    GbE uplink plus a gigabit passthrough port

    Two GbE RJ45 ports: the uplink, which also takes PoE power, and one GbE passthrough port for connecting another device at the installation point. Maximum power consumption is 9W across a supported voltage range of 42.5–57V DC, and Ubiquiti includes a PoE adapter.

    Weatherproof for wall and pole mounting

    Rated IPX6 and weatherproof for outdoor exposed use, with a UV-stabilized polycarbonate enclosure and an aluminum alloy and steel mount. Wall and pole mounts are included, for poles 1–2.5" (25–63.5 mm) in diameter, and it operates from -30 to 60° C (-22 to 140° F).

    Detailed Specifications

    ProductAccess Point U6 Mesh Pro
    WiFi StandardWiFi 6
    Spatial Streams4
    Coverage Area185 m² (2,000 ft²)
    Max. Client Count250+
    UplinkGbE, with (1) GbE passthrough port
    MountingWall, Pole (Mounts Included)
    WeatherproofingIPX6
    Power MethodPoE
    Dimensions343.2 x 181.2 x 60.2 mm (13.5 x 7.1 x 2.4")
    MIMO / 5 GHz2 x 2 (DL/UL MU MIMO)
    MIMO / 2.4 GHz2 x 2 (DL/UL MU-MIMO)
    AntennaIntegrated omnidirectional super antenna
    Antenna Gain / 5 GHz8 dBi
    Antenna Gain / 2.4 GHz8 dBi
    Max. TX Power / 5 GHz27 dBm
    Max. TX Power / 2.4 GHz22 dBm
    Max. BSSIDs8 per Radio
    Channel BandwidthHT 20/40, VHT 20/40/80/160, HE 20/40/80/160 (MHz)
    Operating FrequencyUS/CA: 2400 - 2472 MHz; U-NII-1: 5150 - 5250 MHz; U-NII-2A: 5250 - 5350 MHz; U-NII-2C: 5470 - 5725 MHz; U-NII-3: 5725 - 5850 MHz. Worldwide: 2400 - 2483.5 MHz, 5150 - 5850 MHz (for worldwide, it depends on the regulatory region)
    Max. Data Rate / 5 GHz2.4 Gbps (BW160)
    Max. Data Rate / 2.4 GHz573.5 Mbps (BW40)
    Supported Data Rates / 802.11ax (WiFi 6)7.3 Mbps to 2.4 Gbps (MCS0 - MCS11 NSS1/2, HE 20/40/80/160)
    Supported Data Rates / 802.11ac (WiFi 5)6.5 Mbps to 1.7 Gbps (MCS0 - MCS9 NSS1/2, VHT 20/40/80/160)
    Supported Data Rates / 802.11n6.5 Mbps to 300 Mbps (MCS0 - MCS15, HT 20/40)
    Wireless MeshingYes
    Band SteeringYes
    802.11v BSS Transition ManagementYes
    802.11r Fast RoamingYes
    802.11k Radio Resource Management (RRM)Yes
    Advanced Radio ManagementYes
    Passpoint (Hotspot 2.0)Yes
    WiFi Speed LimitingYes
    WiFi SchedulesYes
    Dynamic RADIUS-assigned VLANYes
    Captive Hotspot Portal / Custom Branding Landing PageYes
    Captive Hotspot Portal / Voucher AuthenticationYes
    Captive Hotspot Portal / Payment-Based AuthenticationYes
    Captive Hotspot Portal / External Portal Server SupportYes
    Captive Hotspot Portal / Password AuthenticationYes
    Captive Hotspot Portal / Guest Network IsolationYes
    Private Pre-Shared Key (PPSK)Yes
    Client Device IsolationYes
    RADIUS over TLS (RadSec)Yes
    Networking Interface(2) GbE RJ45 ports
    Max. Power Consumption9W
    Includes PoE AdapterYes
    Supported Voltage Range42.5–57V DC
    Weight819 g (1.8 lb)
    Pole Mount Diameter1–2.5" (25–63.5 mm)
    Enclosure MaterialUV-stabilized polycarbonate
    Mount MaterialAluminum alloy, steel
    LEDs / SystemWhite/Blue
    Ambient Operating Temperature-30 to 60° C (-22 to 140° F)
    Ambient Operating Humidity5 to 95% noncondensing
    NDAA CompliantYes
    CertificationsCE, FCC, IC, Anatel: 06377-24-08356
    ManagementEthernet, WiFi
    Application Requirements / UniFi NetworkVersion 8.1.127 and later

    All specifications are Ubiquiti's own, from its official tech specs and store pages. Ubiquiti does not state whether the GbE passthrough port outputs PoE. UniFi Network version 8.1.127 or later is required.

    Need-to-Know

    • The U6 Mesh Pro needs the UniFi Network application version 8.1.127 or later, a newer minimum than many other UniFi WiFi 6 access points. Check your controller version before installing.
    • The U6 Mesh Pro is powered by PoE through its uplink port, and Ubiquiti includes a PoE adapter. The supported voltage range is 42.5–57V DC.
    • The second GbE RJ45 port is a passthrough port. Ubiquiti does not state that it supplies PoE power to the connected device, so plan separate power for anything plugged into it.
    • Ubiquiti lists the U6 Mesh Pro as WiFi 6 on the 2.4 GHz and 5 GHz bands only.

    Best For / Customer Benefits

    Customer Benefits

    • 185 m² (2,000 ft²) of coverage from the integrated omnidirectional super antenna
    • A GbE passthrough port for a second wired device at the installation point
    • IPX6 weatherproofing with wall and pole mounts included
    • PoE powered at 9W maximum, with a PoE adapter in the box
    • Wireless meshing, guest portals, PPSK and RadSec in UniFi Network

    Best For

    Outdoor areas, car parks and building perimeters
    Pole-mounted coverage across yards and open spaces
    Sites that need a wired device at the access point location
    Hotels and campuses with indoor and outdoor guest WiFi

    Frequently Asked Questions

    Yes. Ubiquiti describes it as an indoor/outdoor access point, weatherproof for outdoor exposed use, with an IPX6 rating and a UV-stabilized polycarbonate enclosure. Its ambient operating temperature range is -30 to 60° C (-22 to 140° F).

    The U6 Mesh Pro has two GbE RJ45 ports: the GbE uplink and one GbE passthrough port, which lets you connect another wired device at the access point's location. Ubiquiti does not state that the passthrough port outputs PoE, so plan separate power for anything connected to it.

    It is powered by PoE, with a maximum power consumption of 9W and a supported voltage range of 42.5–57V DC. Ubiquiti lists the PoE adapter as included, so it can run from a non-PoE switch port through the adapter.

    Ubiquiti lists UniFi Network version 8.1.127 and later. Once adopted it supports wireless meshing, band steering, fast roaming (802.11r/k/v), guest hotspot portals, PPSK, RadSec and RADIUS-assigned VLANs, and it can be managed over Ethernet or WiFi.

    Ubiquiti gives a pole mount diameter of 1–2.5" (25–63.5 mm). Wall and pole mounts are included, made of aluminum alloy and steel. The access point measures 343.2 x 181.2 x 60.2 mm and weighs 819 g.
