Ubiquiti Access Point U6 Mesh, Indoor/Outdoor WiFi 6, 140 m² Coverage, 250+ Clients, IPX5, PoE

U6-Mesh

Condition: NEW

Dhs. 743.07(exc. Vat)
(exc. Vat)
Dhs. 743.07(exc. Vat)
Shipping calculated at checkout.
    Live stock status

    Confirm Availability & Best Price

    This model is fulfilled through our verified supplier network. Message us for live stock status and pricing.

    Enquire Now
    Genuine Guarantee

    Shop with Confidence: Authentic IT Products from Major Brands.
    Shipping information

    We offer FREE DELIVERY for order over AED 200. Also no additional Cash on Delivery (COD) fee.

    Click here to know more
    Returns information

    No longer required or changed you mind ?

    We have a 7 days return policy

    Click here to know more
    Ubiquiti Access Point U6 Mesh U6-Mesh view 1 atomoffice
    Ubiquiti Access Point U6 Mesh U6-Mesh view 2 atomoffice
    Ubiquiti Access Point U6 Mesh U6-Mesh view 3 atomoffice
    Ubiquiti Access Point U6 Mesh U6-Mesh view 4 atomoffice

    UniFi WiFi 6 Mesh Access Point

    Ubiquiti UniFi U6 Mesh Indoor/Outdoor WiFi 6 Access Point

    The Ubiquiti U6 Mesh is a sleek indoor/outdoor WiFi 6 access point with 6 spatial streams, designed for mesh applications. It covers up to 140 m² (1,500 ft²), handles 250+ connected devices, connects over a GbE uplink and is powered by PoE, with a PoE adapter included. It mounts on a tabletop, wall or pole, and is weatherproof (IPX5) when installed LED side up with the included pole/wall mount accessory.

    Quick Glance

    Wireless Standard
    WiFi 6, 6 spatial streams
    Max Speed
    4.8 Gbps on 5 GHz (BW160)
    Coverage
    140 m² (1,500 ft²)
    Client Capacity
    250+ devices
    Power Type
    PoE (13W max.), adapter included

    Key Features

    Indoor/outdoor, built for mesh

    A sleek cylinder (⌀48.5 x 159.5 mm) designed for mesh applications, with wireless meshing supported. It is rated IPX5 and weatherproof for outdoor exposed use when installed LED side up with the included pole/wall mount accessory, and operates from -30 to 60° C (-22 to 140° F).

    WiFi 6 with 6 spatial streams

    4 x 4 MU-MIMO on 5 GHz and 2 x 2 MU-MIMO on 2.4 GHz. Ubiquiti rates the maximum data rate at 4.8 Gbps on 5 GHz (BW160) and 573.5 Mbps on 2.4 GHz (BW40), with coverage of 140 m² (1,500 ft²) and 250+ connected devices.

    One PoE cable, flexible mounting

    A single GbE RJ45 port carries data and PoE power, with a supported voltage range of 44–57V DC and a maximum power consumption of 13W. Ubiquiti includes a PoE adapter and the mounts for tabletop, wall and pole installation.

    Detailed Specifications

    ProductAccess Point U6 Mesh
    WiFi StandardWiFi 6
    Spatial Streams6
    Coverage Area140 m² (1,500 ft²)
    Max. Client Count250+
    UplinkGbE
    MountingWall, Pole (Mounts Included); tabletop
    WeatherproofingIPX5
    Power MethodPoE
    Dimensions⌀48.5 x 159.5 mm (⌀1.9 x 6.3")
    MIMO / 5 GHz4 x 4 (DL/UL MU-MIMO)
    MIMO / 2.4 GHz2 x 2 (DL/UL MU-MIMO)
    Antenna Gain / 5 GHz5 dBi
    Antenna Gain / 2.4 GHz3 dBi
    Max. TX Power / 5 GHz26 dBm
    Max. TX Power / 2.4 GHz22 dBm
    Max. BSSIDs8 per Radio
    Channel BandwidthHT 20/40, VHT 20/40/80/160, HE 20/40/80/160 (MHz)
    Operating FrequencyUS/CA: 2400 - 2472 MHz; U-NII-1: 5150 - 5250 MHz; U-NII-2A: 5250 - 5350 MHz; U-NII-2C: 5470 - 5725 MHz; U-NII-3: 5725 - 5850 MHz. Worldwide: 2400 - 2483.5 MHz, 5150 - 5850 MHz (for worldwide, it depends on the regulatory region)
    Max. Data Rate / 5 GHz4.8 Gbps (BW160)
    Max. Data Rate / 2.4 GHz573.5 Mbps (BW40)
    Supported Data Rates / 802.11ax (WiFi 6)7.3 Mbps to 4.8 Gbps (MCS0 - MCS11 NSS1/2/3/4, HE 20/40/80/160)
    Supported Data Rates / 802.11ac (WiFi 5)6.5 Mbps to 3.4 Gbps (MCS0 - MCS9 NSS1/2/3/4, VHT 20/40/80/160)
    Supported Data Rates / 802.11n6.5 Mbps to 600 Mbps (MCS0 - MCS31, HT 20/40)
    Wireless MeshingYes
    Band SteeringYes
    802.11v BSS Transition ManagementYes
    802.11r Fast RoamingYes
    802.11k Radio Resource Management (RRM)Yes
    Advanced Radio ManagementYes
    Passpoint (Hotspot 2.0)Yes
    WiFi Speed LimitingYes
    WiFi SchedulesYes
    Dynamic RADIUS-assigned VLANYes
    Captive Hotspot Portal / Custom Branding Landing PageYes
    Captive Hotspot Portal / Voucher AuthenticationYes
    Captive Hotspot Portal / Payment-Based AuthenticationYes
    Captive Hotspot Portal / External Portal Server SupportYes
    Captive Hotspot Portal / Password AuthenticationYes
    Captive Hotspot Portal / Guest Network IsolationYes
    Private Pre-Shared Key (PPSK)Yes
    Client Device IsolationYes
    RADIUS over TLS (RadSec)Yes
    Networking Interface(1) GbE RJ45 port
    Max. Power Consumption13W
    Includes PoE AdapterYes
    Supported Voltage Range44–57V DC
    Weight400 g (14.1 oz)
    Enclosure MaterialPolycarbonate, aluminum
    Mount MaterialPolycarbonate
    LEDs / SystemWhite/Blue
    Ambient Operating Temperature-30 to 60° C (-22 to 140° F)
    Ambient Operating Humidity5 to 95% noncondensing
    NDAA CompliantYes
    CertificationsCE, FCC, IC, SRRC, Anatel: 02111-22-08356
    ManagementEthernet
    Application Requirements / UniFi NetworkVersion 6.0.45 and later

    All specifications are Ubiquiti's own, from its official tech specs and store pages. Weatherproofing applies when the U6 Mesh is installed LED side up with the included pole/wall mount accessory.

    Need-to-Know

    • Ubiquiti states the U6 Mesh is weatherproof only when installed LED side up with the included pole/wall mount accessory. Mount it that way for any outdoor exposed location.
    • The U6 Mesh is powered by PoE through its single GbE RJ45 port, and Ubiquiti includes a PoE adapter. The supported voltage range is 44–57V DC.
    • Ubiquiti lists the U6 Mesh as WiFi 6 on the 2.4 GHz and 5 GHz bands only.
    • Managing the U6 Mesh needs the UniFi Network application, version 6.0.45 or later.

    Best For / Customer Benefits

    Customer Benefits

    • One access point for indoor and outdoor use, rated IPX5
    • WiFi 6 with 6 spatial streams and up to 4.8 Gbps on 5 GHz
    • PoE adapter and wall/pole mounts included by Ubiquiti
    • Wireless meshing, guest portals, PPSK and RadSec in UniFi Network

    Best For

    Courtyards, terraces and outdoor seating areas
    Extending UniFi WiFi by mesh where cabling is difficult
    Warehouses, workshops and covered outdoor spaces
    Offices that want a discreet tabletop or wall access point

    Frequently Asked Questions

    Yes. Ubiquiti describes it as an indoor/outdoor access point rated IPX5, and weatherproof for outdoor exposed use when installed LED side up with the included pole/wall mount accessory. Its ambient operating temperature range is -30 to 60° C (-22 to 140° F).

    It is powered by PoE over its single GbE RJ45 port, with a supported voltage range of 44–57V DC and a maximum power consumption of 13W. Ubiquiti lists the PoE adapter as included, so it can run from a non-PoE switch port through the adapter.

    Ubiquiti rates one U6 Mesh for 140 m² (1,500 ft²) of coverage and 250+ connected devices. Real coverage depends on walls, open space and interference, so larger sites usually plan several access points managed together in UniFi Network.

    Ubiquiti lists tabletop, wall and pole mounting, with the wall and pole mounts included. The mount is made of polycarbonate and the access point measures ⌀48.5 x 159.5 mm (⌀1.9 x 6.3").

    The U6 Mesh supports wireless meshing in UniFi Network, so it can extend UniFi WiFi to places where running a cable is difficult, as well as working as a wired access point over its GbE uplink. It also supports band steering, fast roaming (802.11r/k/v), guest hotspot portals, PPSK and RADIUS-assigned VLANs.
