Ubiquiti 100G LR4 Single-Mode Optical Module, QSFP28, Duplex LC UPC, 10 km

UACC-OM-QSFP28-LR4

Condition: NEW

Dhs. 1,464.75(exc. Vat)
(exc. Vat)
Dhs. 1,464.75(exc. Vat)
Shipping calculated at checkout.
    Live stock status

    Confirm Availability & Best Price

    This model is fulfilled through our verified supplier network. Message us for live stock status and pricing.

    Enquire Now
    Genuine Guarantee

    Shop with Confidence: Authentic IT Products from Major Brands.
    Shipping information

    We offer FREE DELIVERY for order over AED 200. Also no additional Cash on Delivery (COD) fee.

    Click here to know more
    Returns information

    No longer required or changed you mind ?

    We have a 7 days return policy

    Click here to know more
    Ubiquiti 100G LR4 Single-Mode Optical Module UACC-OM-QSFP28-LR4 view 1 atomoffice
    Ubiquiti 100G LR4 Single-Mode Optical Module UACC-OM-QSFP28-LR4 view 2 atomoffice
    Ubiquiti 100G LR4 Single-Mode Optical Module UACC-OM-QSFP28-LR4 view 3 atomoffice
    Ubiquiti 100G LR4 Single-Mode Optical Module UACC-OM-QSFP28-LR4 view 4 atomoffice

    Ubiquiti QSFP28 Optical Module

    Ubiquiti 100G LR4 Single-Mode Optical Module (UACC-OM-QSFP28-LR4)

    The Ubiquiti 100G LR4 Single-Mode Optical Module is a QSFP28 transceiver for 100 Gbps links of up to 10 km over single-mode fiber. It uses a duplex LC UPC connector and Ubiquiti lists it as compatible with QSFP28 and QSFP+ interfaces, for high-capacity uplinks between core switches and buildings. This listing is the single unit, UACC-OM-QSFP28-LR4. Fiber cable is not included.

    Quick Glance

    Data Speed
    100 Gbps
    Connector Interface
    QSFP28, duplex LC UPC
    Fibre Type
    Single-mode fiber
    Wavelength
    1295 / 1300 / 1304 / 1309 nm
    Max Distance
    10 km (6.2 mi)

    Key Features

    100 Gbps over single-mode fiber up to 10 km

    Ubiquiti rates the module for a 100 Gbps data rate and a supported cable distance of 10 km (6.2 mi) over single-mode fiber. It uses the QSFP28 form factor and Ubiquiti lists it as compatible with QSFP28 and QSFP+ interfaces.

    LR4 optics on a duplex LC UPC connector

    The module has a duplex LC UPC connector, so a link uses a single-mode fiber pair. Ubiquiti lists four TX and RX wavelengths for this LR4 module: 1295 / 1300 / 1304 / 1309 nm. Fiber cable is not included and is bought separately.

    4 W maximum, 0 to 70° C operation

    Maximum power consumption is 4 W per Ubiquiti's specification, and the ambient operating temperature range is 0 to 70° C (32 to 158° F). It is a Class 1 laser product to IEC/EN 60825-1:2014 and is sold as a single unit.

    Detailed Specifications

    Product100G LR4 Single-Mode Optical Module
    Manufacturer Part NumberUACC-OM-QSFP28-LR4 (single unit)
    Form FactorQSFP28
    Supported Data Rate100 Gbps
    Compatible InterfacesQSFP28 and QSFP+
    Pack Options (Ubiquiti)Single Unit
    ConnectorDuplex LC UPC
    Supported MediaSingle-Mode Fiber
    TX Wavelength1295 / 1300 / 1304 / 1309 nm
    RX Wavelength1295 / 1300 / 1304 / 1309 nm
    Supported Cable Distance10 km (6.2 mi)
    Fiber CableNot included
    Max. Power Consumption4 W
    Ambient Operating Temperature0 to 70° C (32 to 158° F)
    Laser ClassificationCLASS 1 LASER PRODUCT, IEC/EN 60825-1:2014
    WarningDo not look into the ends of the fiber optic cable or SFP module while converters are powered.

    Specifications are from Ubiquiti's technical specifications page and official store listing for the 100G LR4 Single-Mode Optical Module. Ubiquiti does not publish a weight for this module.

    Need-to-Know

    • Fiber cable is not included. The module needs single-mode fiber terminated with a duplex LC UPC connector.
    • Ubiquiti lists the module as compatible with QSFP28 and QSFP+ interfaces but states only the 100 Gbps data rate; it does not state the link speed when fitted in a QSFP+ port.
    • This is a single unit (UACC-OM-QSFP28-LR4). Ubiquiti publishes no weight for the module.
    • Class 1 laser product: do not look into the ends of the fiber optic cable or the module while converters are powered.

    Best For / Customer Benefits

    Customer Benefits

    • 100 Gbps over a single duplex single-mode fiber pair.
    • Supported cable distance of up to 10 km per Ubiquiti's specification.
    • Standard duplex LC UPC connector for common single-mode patch leads.
    • Supplied with a VAT invoice for business purchasing.

    Best For

    100 Gbps uplinks between core switches
    Long single-mode fiber runs between buildings on one site
    Data centre and server room aggregation with QSFP28 ports

    Frequently Asked Questions

    Ubiquiti rates the 100G LR4 Single-Mode Optical Module for a 100 Gbps data rate and a supported cable distance of 10 km (6.2 mi) over single-mode fiber.

    Ubiquiti lists the module as compatible with QSFP28 and QSFP+ interfaces. It is a QSFP28 form-factor transceiver. Ubiquiti does not state the data rate it runs at in a QSFP+ port, so check with us before planning a QSFP+ link.

    It has a duplex LC UPC connector and works with single-mode fiber. Ubiquiti lists TX and RX wavelengths of 1295 / 1300 / 1304 / 1309 nm for this LR4 module.

    No. Ubiquiti states that fiber cable is not included. You need single-mode fiber with a duplex LC UPC connector at each end of the link.

    Planning a 100G single-mode link?

    Tell us the distance and the switches at each end, and we will help you confirm this QSFP28 module and the fiber you need.
