Epson SureColor UV Flatbed Printer
Epson SureColor V7000 UV Flatbed Printer for Rigid and Flexible Media
The Epson SureColor V7000 is a UV flatbed printer for sign makers and promotional producers who print directly onto objects, rigid boards and flexible media. It uses an Epson Micro Piezo print head with a 10-colour UltraChrome UV inkset at 720 x 1440 dpi, over a maximum print area of 2.5m x 1.25m, and prints white, colour and varnish simultaneously.
Quick Glance
Key Features
10-colour UltraChrome UV inkset
An Epson Micro Piezo print head lays down a 10-colour UltraChrome UV inkset at 720 x 1440 dpi. White, colour and varnish can be printed simultaneously, and a white ink circulation system is part of the maintenance system.
2.5m x 1.25m flatbed for direct-to-object work
The flatbed takes a maximum print size of 2.5m x 1.25m and prints directly onto objects, rigid boards and flexible media, so sign makers and promotional producers can widen what they offer. The machine measures 4635 x 2768 x 1730 mm (W x D x H).
A complete Epson solution
Epson supplies the printheads, ink, firmware and software as one solution. Epson Edge Print is included, Epson Cloud Solution PORT is supported, and Epson lists a UV Flatbed Controller, an Ionizer and an LED Curing System as optional additions.
Detailed Specifications
Specifications are Epson's own, from the Epson UAE product page for C11CH89101A0. Rows Epson's page states without a unit or with an internal code (ink tank capacity, single sheet and rigid board thickness, product range) are left out rather than guessed.
Need-to-Know
- The V7000 runs on 200 V - 240 V only, so plan the power supply at the installation site before delivery.
- Epson's UAE page does not publish this printer's weight, print speed, maximum media thickness or interface ports. Ask us if you need any of these before ordering.
- At 4635 x 2768 x 1730 mm the V7000 needs a dedicated production space; check access routes and floor area with us before ordering.
Best For / Customer Benefits
Customer Benefits
- A 2.5m x 1.25m print area for large boards and many small objects at once.
- Simultaneous white, colour and varnish printing from one 10-colour inkset.
- Printheads, ink, firmware and software all from Epson, with Epson Edge Print included.
- Expert advice from AtomOffice on planning a UV flatbed installation.
Best For
Frequently Asked Questions
Epson positions the V7000 for direct-to-object UV printing on rigid and flexible media, for sign makers and promotional producers. The maximum print size is 2.5m x 1.25m.
It uses Epson's UltraChrome UV ink as a 10-colour inkset. White, colour and varnish can be printed simultaneously, and Epson lists a white ink circulation system as part of its maintenance system.
Epson Edge Print is included, and the printer supports Epson Cloud Solution PORT. Epson lists a UV Flatbed Controller, an Ionizer and an LED Curing System as optional solutions.
Epson lists a supply voltage of 200 V - 240 V, 50 Hz - 60 Hz, and dimensions of 4635 x 2768 x 1730 mm (width x depth x height). Plan both before installation.
Planning an Epson SureColor V7000 installation?
Ask us for a quote on the SureColor V7000 UV flatbed printer, or for help with site, power and optional curing and controller choices.
