Canon imagePROGRAF TC20 Large Format Desktop Plotter - 24" Roll, A3/A4 Feeder atomoffice

Canon imagePROGRAF TC20M Large Format Desktop Plotter - 24" Roll, A3/A4 Feeder with scanner atomoffice

Canon imagePROGRAF Large-Format Printer

Canon imagePROGRAF TC20M Large Format Desktop Plotter - 24" Roll, A3/A4 Feeder (with scanner)

The Canon imagePROGRAF TC-20M is a 4 Colour 24" large-format printer from Canon with a scanner — Pigment inks: 4 colour BK/C/M/Y, 2,400 x 1,200 dpi. Supplied by AtomOffice across Dubai, Abu Dhabi and the wider UAE — contact us for a quotation.

Quick Glance

Printer type

4 Colour 24"

Print resolution

2,400 x 1,200 dpi

Ink

Pigment inks: 4 colour BK/C/M/Y

Media width

Roll paper: A3, A2, A2+, A1, B2, B3, 18'', 24'', 17''

Key Features

4 Colour 24" large-format printer

Canon Pigment ink 4 colours integrated type (4 chips per print head x 1 print head). Print resolution: 2,400 x 1,200 dpi.

Ink

Pigment inks: 4 colour BK/C/M/Y. Bundled Starter Ink: 280ml (70mlx4 for BK, C, M, Y) / Sales Ink: 70ml (BK, C, M, Y).

Built-in scanning

Flatbed CIS colour scanner. Media: Roll paper: A3, A2, A2+, A1, B2, B3, 18'', 24'', 17'' / Cut sheet: 210mm - 297mm.

Detailed Specifications

PrintInkPrint SpeedMediaConnectivityScannerGeneral

Printer Type4 Colour 24"

Print TechnologyCanon Pigment ink 4 colours integrated type (4 chips per print head x 1 print head)

Print Resolution2,400 x 1,200 dpi

Number of NozzlesTotal: 4352 nozzles BK: 1280 nozzles C, M, Y: 1024 nozzles each

Line Accuracy±0.1% or less / User adjustments necessary. Printing environment and media must match those used for the adjustments.

Printer LanguagesUSB Memory Direct Print: PDF, JPEG (Exif ver2.2 / 2.21 / 2.3)

Ink TypePigment inks: 4 colour BK/C/M/Y

Ink CapacityBundled Starter Ink: 280ml (70mlx4 for BK, C, M, Y) / Sales Ink: 70ml (BK, C, M, Y)

User Replaceable ItemsInk Tank: PFl-050 (70ml) / Print Head: PF-08 / Maintenance Cartridge: MC-32

CAD DrawingPlain paper (A1, B&W): / 0:33 (Standard) / Plain Paper (A1, Colour): / 1:03 (Standard)

PosterPlain Paper (A1) / 1:10 (Fast) / 2:08 (Standard) / Coated Paper (A1) / 3:10 (Fast) / 6:05 (Standard)

Media Feed and OutputRoll Paper: One Roll, Front-loading, Front Output / Cut Sheet: Auto sheet feeder

Media WidthRoll paper: A3, A2, A2+, A1, B2, B3, 18'', 24'', 17'' / Cut sheet: 210mm - 297mm

Media ThicknessRoll / Cut: 0.08mm - 0.28mm

Maximum Printable LengthRoll paper: 4m / Cut sheet: 432mm

Maximum Media Roll Diameter110mm

Media Core SizeInternal diameter of roll core: 2"

Media Feed CapacityRoll Paper: One roll / Cut Sheet: 100 sheets(A4), 50 sheets (A3)

Standard InterfacesUSB A Port: USB Memory (Direct Print) - PDF / JPEG (Exif ver2.2 / 2.21 / 2.3) / USB B Port: Hi-Speed USB / Ethernet: IEEE802.3u(100BASE-TX) / IEEE802.3(10BASE-T) / Wireless LAN: IEEE802.11n / IEEE802.11g / IEEE802.11b / *Please refer to the user manual how to activate / deactivate the wireless LAN

Standard Memory1GB / Expansion slot: No

Other Supported Job Submission ProtocolsApple AirPrint, Mopria, Chrome OS

Scan TechnologyFlatbed CIS colour scanner

Maximum Resolution (dpi)Main scan X sub scan: 1,200 x 2,400 dpi / *Optical resolution is based on the ISO 14473 standard and represents the maximum sampling rate for scanning documents.

Line Scanning SpeedColour: 3.5 ms / line at 300 dpi / Grayscale / Monochrome: 1.5 ms / line at 300 dpi

Maximum Document SizeA4 / LTR(216 x 297mm)

Physical Dimensions and WeightW x D x H / Main Unit / 968 x 545 x 395 mm (ASF Opened) / 968 x 525 x 245 mm (ASF Closed) / 33 kg (exclude ink bottle, include print head) / Main Unit + Desktop Basket (BU-06) / 968 x 825 x 965* mm (Basket Opened) / 968 x 525 x 965* mm (Basket Closed) / 34 kg (exclude ink bottle, include print head) / *Height above which cloth does not touch the floor when opening the desktop basket / Main Unit + Stand + Basket (SD-24) / 968 × 870 × 874 mm (Basket Opened) / 968 × 707 × 874 mm (Basket Closed) / 42 kg (exclude ink bottle, include print head)

Packaged Dimensions and WeightPrinter (Main unit): 1120 x 726 x 406 mm, 45kg / Desktop Basket (BU-06): 798 x 301 x 111 mm, 1.8kg / Stand + Basket (SD-24): 1055 x 824 x 268 mm, 16kg

Power SupplyAC 100-240V (50-60Hz)

Power ConsumptionOperation: 28W or less / Sleep mode: 2.4W or less / Default setting for the time to enter the Sleep mode: Approx. 5 minutes / Power off: 0.3W or less

Optional ItemsDesktop Basket: BU-06 / Printer Stand and Basket: SD-24

Specifications are provided by the manufacturer and may be updated or changed without prior notice. AtomOffice is not responsible for any discrepancies between the information shown here and the manufacturer's official documentation.

Official & Recommended Options

Desktop Basket BU-06 and Printer Stand SD-24

Optional Desktop Basket BU-06 and Printer Stand with Basket SD-24.

Canon PFI-050 (70 ml) Ink Tank

Genuine Canon PFI-050 70 ml ink tank (BK, C, M, Y) for the TC-20M.

Need one of these options? Contact us and we will confirm availability and the right fit for your printer.

Frequently Asked Questions

What paper widths does the Canon imagePROGRAF TC-20M take?

Canon lists: Roll paper: A3, A2, A2+, A1, B2, B3, 18'', 24'', 17'' / Cut sheet: 210mm - 297mm. Full media details are in the Media tab above.

Which ink does it use?

Pigment inks: 4 colour BK/C/M/Y. Replaceable items: Ink Tank: PFl-050 (70ml) / Print Head: PF-08 / Maintenance Cartridge: MC-32.

How fast does it print?

Canon gives these times for a CAD drawing: Plain paper (A1, B&W): / 0:33 (Standard) / Plain Paper (A1, Colour): / 1:03 (Standard). Poster times are in the Print Speed tab above.

Can you help me choose the right configuration?

Yes — message us what you print, the widths you need and your volumes, and we will recommend the right Canon model and quote it.

What's in the Box

Printer
1 Print head
Power Cable
1 Set of starter ink tanks
Installation Guide
Safety / Standard Environment leaflet
EU Biocide Sheet
LFP Eur Address Sheet
Flange protective materials sheet
